Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode

Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode

  • Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode
  • Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode
  • Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode
  • Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode
  • Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode
Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCXK
Certification: ISO,CE,FCC,UL
Model Number: SCXK-P4.81
Payment & Shipping Terms:
Minimum Order Quantity: Negotiations
Price: Negotiations
Packaging Details: Wooden and flight cases,it's up to you.
Delivery Time: 12-15 working days after receiving your down payment.
Payment Terms: T/T, Western Union
Supply Ability: 5000 sqms/month
Contact Now
Detailed Product Description
Pixel Pitch: 4.81mm Control System: Nova
Type Of Cabinet: Die-cast Aluminum/Iron Working Voltage: DC5V
Outdoor Options: P3.91,P4,P4.81,P5,P5.95,P6,P6.67,P8,P10 Payment: T/T,Western Union
Application Places: Shopping Mall,Stations,Airports,Commercial Centure... Certifications: CE,ISO,FCC,UL.
High Light:

sphere led display

,

full color led screen



Soft Module Flexible Outdoor Full Color LED Display P4.81 1/13Scan Mode



Short details:

1.High brightness LED lamps and good quality plastic kit.
2.High contrast ratio, outstanding display effect.
3.Light weight, easy to assemble and dismantle.
4.Maintenance can be a single point or single lamp.
5.Good heat dissipation capability because of the unique design of vent fan.



Specifications of products:

Flexible Outdoor Full Color LED Display P4.81
Resolution/mm 4.81
Pixel configuration 1R1G1B
Pixel density/pixels/m² 43222/square meter
Module resolution 52*52mm
Module size/mm 250*250mm
View distance 5-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode

alternating driving current

Scanning mode 1/13
Fresh rate 60Hz
Refresh frequency >3000Hz
Control mode

Asynchronous,3G,4G,Wifi

Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Aging hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Waterproof Ip65
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode 0

Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode 1



Our service:



1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 24 months.
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.

Soft Module Flexible Large Outdoor Led Display Screens P4.81 1/13Scan Mode 2





Welcome to visit our website and inquire us more info,waiting for you all the time!!!
