Place of Origin: | China |
Brand Name: | SCXK |
Certification: | CE/ROHS/FCC/SGS |
Model Number: | p3 |
Minimum Order Quantity: | negotiation |
---|---|
Price: | negotiation |
Packaging Details: | Packed in wooden case and flight case for outer packing |
Delivery Time: | 10 working days after received your payment |
Payment Terms: | T/T or western Union |
Supply Ability: | 5,000/ Sq m per month |
Product Name: | Indoor P4 Led Display | Module Size(W * H): | 256mm*128mm |
---|---|---|---|
Standard: | CE/ROHS/FCC/ISO2001 | Tube Chip Color: | Full Color |
Pixel Pitch: | 4mm | Resolution: | 64*32 |
High Light: | led stage display,stage led display |
Rgb Clear Stage Led Screens / P3.91 Indoor Full Color Led Display For Staging Show
Shenzhen Shichuangxinke Eletronic Co., Ltd focuses on science and technology. It cooperates with Semiconductor Institute of famous University in China on scientific research and interaction of talented persons. With the concept of technological cooperation and independent innovation, it develops a series of new products with their own intellectual property. Some unique international advanced technologies are applied to production of various kinds of indoor and outdoor video display system, LED video shining letter and unique fore maintenance and rear maintenance product line, such as programmable hardware nonlinear vision correction,
Point-to-point control and detection, chromatic multimedia output, large scale integrated circuit and programmable ultra large scale integrated circuit and etc, so that LED display images will be clearer with more hierarchy and brighter color and products will be of environmental protection and energy saving with high luminance and long service life and excellent stability which reach international standard, have ready sale in Shenzhen, Guangzhou, Wuhan, Ningxia, Xinjiang, Neimenggu, Hong Kong, Taiwan, USA, South America, Southeast Asia and Middle East, and win great favor from customers.
Pixel pitch | 4mm | Module size | 256×128mm |
Pixel configuration | 1R1G1B | Module resolution | 64×64dots |
View angle | 160°/140° | Pixel density | 62500dots/m² |
LED encapsulation | SMD2121 | Refresh rates | >500Hz |
Driving Method | 1/16scan, constant current | Max power consumption | 850w/m² |
Brightness | >2500nits (cd/m²) | Average power consumption | 300w/m² |
Working voltage | AC110/220V | Working temp | -20°C to +55°C |
Best viewing distance | >4m-50m | Working humidity | 10%~90% |
LED parameters | R:625nm±5.0nm IV:400-500mcd | MTBF | >5,000 hours |
G:525nm±2.5nm IV:1,800-2,200mcd | Gray level | RGB/8192/14bit | |
B:470nm±2.5nm IV:350-450mcd | Lifespan | >100,000 hours |
♦ Production process:
1) Incoming Inspection→2)SMD→3)Plug-in
→4) Wave Soldering→5)After Welding→6)Testing
→7) Semi Finished Aging→8)Module Assembly
→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing
♦ Packaging and shipping
we can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.
we can choose the best shippment which is convenient to you!
SCXK group can give you the short delivery time and With the large production ability ,
you can feel free about this . By air ,by train, by sea?
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ Applications
--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.
♦ FAQ
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
