Indoor full color SMD2121P4 die cast aluminum cabinet stage led screens with 3 years

Indoor full color SMD2121P4 die cast aluminum cabinet stage led screens with 3 years

  • Indoor full color  SMD2121P4 die cast aluminum cabinet stage led screens with 3 years
  • Indoor full color  SMD2121P4 die cast aluminum cabinet stage led screens with 3 years
Indoor full color  SMD2121P4 die cast aluminum cabinet stage led screens with 3 years
Product Details:
Place of Origin: Made in china
Brand Name: SCXK
Certification: CE,ROHS, FCC.UL.CUL
Model Number: SCXK-P4
Payment & Shipping Terms:
Minimum Order Quantity: one cabinet sand one module can be avaiable.
Price: Negotiable
Packaging Details: wooden box, flight case, paper box can be available( All kinds of the box will guarantee the safety of the led display
Delivery Time: within 7-10days, the led disdplay can be sent to you after your payment
Payment Terms: D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Contact Now
Detailed Product Description
Material: Die Cast Aluminum Cabinet Cabinet Size: 512mm X512mm
Module Size: 256mm X128mm Warranty: 3 Years
Refresh Rate: 3000hz Led Chip: Epistar
Color: Full Color Scan Way: 1/16scan
Dot Density: 62500dots/sqm
High Light:

led stage display

,

stage led display

Indoor full color SMD2121P4 die cast aluminum cabinet stage led screens with 3 years



SCXK has been specialized in LED field since 2005. We are a leading manufacturer an provider of technical solution of full color indoor

and outdoor led display,rental LED display, led modules where in Shenzhen city Guang dong province,China.



My company's customer service tenet is: "Clients are always the first.”

we manage the satisfaction and loyalty of customers;

we improve the ability of customer service staffs;

we properly handle the complaints from our customers with an optimistic attitude and make the greatest efforts to customer satisfaction.

We put in time every need of our clients from all aspects into our consideration and serve it with our most professional ability.



The detailed parameter of indoor P4 stage led display as follows.



The indoor die cast aluminum cabinet hanging and rental usage led display
P2 1/32scan 128X64mm 64x32 512x512mm 3 in 1 250000
p2.5 1/32scan 160x160mm 64x64 480x480mm 3 in 1 160000
p3 1/32scan 192x192mm 64x64 576x576mm 3 in 1 111111
p4 1/32scan 256x128mm 64x32 512x512mm 3 in 1 62500
p5 1/16scan 320x160mm 64x32 640x640mm 3 in 1 40000
p6 1/16scan 192x192mm 32x32 576x576mm 3 in 1 27777



LED Lamps Type SMD2121 (High Brightness LEDs)
LED Standard Real Pixel(1R1G1B)
Red Wavelength 625-630nm
LED Module Pixel Pitch 4mm
Module Size 512mm x512mm
Module Resolution 128*128dots
LED Cabinet Cabinet Size 512mmX512mm
Cabinet Resolution 128pixels *128pixels
Cabinets Material Sealed Iron Cabinet
led screen Pixel Density 62500pixels/sq.m
Drive IC MBI5124
Power Supply Series connection
Brightness >2500cd/sqm
Display Color 16.7million
Viewing Angle 160°(Horizontal),110°(Vertical)
Best Viewing Distance 4m~200m
Max Power Consumption 600 w/sq.m
Weight 22kgs/sq.m
Refresh Rate 3000hz
Input Voltage AC220V/50H or AC110V/60H
Output Voltage DC5V,40A
Grey Scale Levels 16bit
Display Colors R(1024) x G(1024) x B(1024)
MTBF 10,000 hours
Life-span 100,000 hours
Drive Mode 1/16 scaning
Working Humidity 10%~99%
Control System Control method Synchronization & Asynchronization
Control System (software) linsn
Software LED Studio
PC Operating system Microsoft Windows 7, 98, 2000, XP and Vista



Indoor full color  SMD2121P4 die cast aluminum cabinet stage led screens with 3 years 0

 Free Training

Via internet, or in our workshop, we provide all the training including process of operation, installation, maintenance, system set up, etc.

Warranty

1, 2-3years accrording to the contract .From beginning of installation finished the led display, we will be responsible for all the quality problem.

2, After the completion of the project, we will conduct life maintenance of the system continuously and update the and software.

3, For the hardware equipment, we only collect expenses on components.
