Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P1.923 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | T/T or western Union |
| Supply Ability: | 5000sqm per month |
| Product Name: | Indoor Module | Module Size(W * H): | 246mm*246mm |
|---|---|---|---|
| Standard: | CE/ROHS/FCC/ISO2001 | Tube Chip Color: | Full Color |
| Pixel Pitch: | 1.923mm | Module Qty: | 1pcs |
| Type: | Free Standing | Resolution(W*H): | 128dots*128dots |
| High Light: | led full color screen,indoor led display screen |
||
supper high definition indoor p3 led panels,indoor full color led display
Shenzhen Shichuangxinke Co.,Ltd was located in Shenzhen,We are the high technology enterprise Company,and specialized in research,development,production and sales the Rental LED display screen,Fix Install LED display sreen etc.it is a full color LED display, LED screen and LED should products as the main business, scientific research, development, manufacturing, and engineering for the integration of high-tech enterprises.
The company is located in shenzhen Longhua district, has a modern research and development base, equipped with the world advanced level of scientific research, production, analysis, testing equipment, has a high-quality scientific research team, committed to the development of the industry application in the field of photoelectric photoelectric products and services. Company strictly abide by the "honesty, keep promise" of the enterprise purpose, to build the company into a cross industry step by step, cross-regional, across the international large enterprises with comprehensive operation ability.
We are one of the most advanced LED display manufacturers in China,and we have formed the marketing station based on the frame of domestic bidding,domestic marketing channel expansion,international direct sales and agent.
We warmly welcome clients from all over the world to contact us for more information,and we are looking forward to establishing long-term business relationship with you.
Specification
|
Item |
Technical Specification |
|
Pixel |
Pixel pitch: 1.923mm |
|
Pixel configuration: 1R1G1B |
|
|
Brightness: Red: 600mcd Green: 2300mcd Blue: 500mcd |
|
|
Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm |
|
|
Module |
Module size: 246mmx246mm |
|
Module resolution:128x128pixels |
|
|
Cabinet |
Cabinet resolution:256pixelsx256pixels |
|
Cabinet material: Steel |
|
|
Gross weight: 4.5kg |
|
|
Module quantity: 2*2=4pcs |
|
|
Cabinet size: 492mm*492mm |
|
|
Power consumption : Max.:1000W/m² Average: 400W/m² |
|
|
Screen parameter |
Drive method: 1/32 scan |
|
Brightness: 2500cd/m² |
|
|
IC driver: MBI 5024 |
|
|
Density: 270420pixel/m² |
|
|
Whole display flatness: ≤ 1mm juncture |
|
|
Best view distance: ≥ 2m |
|
|
Viewing angle: Horizontal: 120° Vertical: 90° |
|
|
Humidity(RH): ≤ 90~95% |
|
|
Working temperature: from -15°C~ +60°C |
|
|
Working voltage: AC220V/110V±20% |
|
|
Refresh frequency: ≥ 300Hz(Linsn) |
|
|
Frame rate: ≥ 540Hz |
|
|
Protection grade: IP54 |
|
|
MTBF: More than 10000hrs |
|
|
Life time: 100,000 hrs |
|
|
Control system |
Control system: Linsn |
|
Signal interface: DVI |
|
|
Communication distance: The shielded twisted-pair cable transmission distance for 100 meters, the biggest up to 140 m. Multimode fiber of up to 500 meters, the single-mode optical fiber to 20 kilometers |
|
|
Systems operating platforms :XP,WINDOWS(WIN95,WIN98,WIN2000) |
|
|
Input Signal:RF,S-VIDEO,RGBTV,YUT,YC,COMPOSITION |
|
|
Image adjustment:contrast, tonal, the color saturation, gray calibration coefficient, color range, image variable times, etc |
|
|
Life span:100,000 hours |
|
|
Out-of Control rate:0.0001 |
|
|
Control system:Synchronized |
Outdoor LED Display series :
1. Automatic brightness control,super processing ability,strong colour restoration.
2. Support various interfaces and signal sources.
3. Advanced digital control technology, excellent effect.
4. High brightness,even in direct,full-on sunlight to ensure you attract more audience to get short ROI of your full color outdoor led display screen's investment.
5. Antiseptic and durable, can be used outdoor in all weather.
LED module has easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display system.
With full aluminum alloy structure for light weight and waterproof advantages, HJY outdoor led display is an perfect external multimedia LED display system designed for changeable and adverse outdoor environment.
Indoor LED Display series :
The indoor led screen uses high-quality LED, which has high efficiency luminescence,decreased attenuation of brightness,high stability and reliability. Super uniformity in color. Low-budget, high pixel density,more vivid and stable pictures(No Flickering). The ultra-slim and ultra-light weight structure of indoor full color led display,increased design opportunities and lower transportation costs. SMD technology takes super wide viewing angle for the LED display; better color performance,higher contrast ratio and higher refresh rate. The super thin rental indoor led display features low weight,special rigging system for simplified service,hassle-free mounting, easy configuration and maintenance,and several other enhancements that are unmatched in the industry.
The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available
The wire or wireless controll system are available .( 3g and wifi controll will be welcome)
Payment and delivery
1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
