Place of Origin: | China |
Brand Name: | SCXK |
Certification: | CE/ROHS/FCC/ISO/UL |
Model Number: | SCXK -P4 |
Minimum Order Quantity: | 5sqm |
---|---|
Price: | negotiation |
Packaging Details: | flight case, wooden case, carton, it is up to you. |
Delivery Time: | 7-10 working days after receive your payment |
Payment Terms: | T/T, Western Union, MoneyGram, MoneyGram, D/A, L/C |
Supply Ability: | 5000sqm per month |
Product Name: | Stage Led Screen Series | Usage: | Outdoor |
---|---|---|---|
Pixels: | 41mm | Led Type: | SMD2727 |
Tube Chip Color: | Full Color | Display Function: | Video |
Waterproof: | IP67 | Cabinet: | Aluminum |
High Light: | led stage display,stage led display |
High Brightness P4 SMD indoor full color rental led display screen / P4 stage led
Features of p4 indoor led screen
1. High quality LED chip and high anti-static electricity capacity.
2. Large viewing angle and smooth displaying provide excellent visual effect from every angle.
3. The integration of lamp and driving IC,together with with the multi-circuit structure,achievs evenly-distributed current, low power consumption and fast heat dissipation.
4. Ultra high brightness, low attenuation, high reliability and weather ability.
5. High contrast ratio. Adopting black lamps can improve the contrast ratio by 50%.
6. High refresh rate, high gray scale, ghost-canceling, low power consumption, low EMI, anti-creeping, multi-route redundancy backup-supporting, and dot-by-dot-calibration.
Application scope of p4 indoor led screen: Widely applied to traffic information distribution of station, quay and airport,conference,shoppingmall, brand presentantion, TVstation, stage show, concert and so on.
Specification | Indoor LED P4 Module 3in1 SMD in Stock | |
Model NO | P4 LED module | |
LED Assembly Mode | SMD2121 | |
Pixel Pitch | 4mm | |
Pixel Density | 62500 | |
Pixel configuration | 1R1G1B | |
Moudle resolution(L*H/dots) | 64*32 | |
Moduel size(L*H/mm) | 256*128 | |
Drive Mode | 1/16 scan | |
Refresh Rate | ≥180Hz | |
Bightness | 2000cd/m2 | |
Best Viewing distance | ≥4m | |
White Balance (X:Y:) | 0.29 0.31 | |
Grade Level | 16.67 colors(full color type with synchronous control) | |
Viewing Angle | Horizontally >160° / Vertically >130° | |
Screen Lifetime | ≥ 100,000 hours | |
Driving IC | MBI5024 | |
Change Frame Frequency | ≥ 60Hz | |
Control System |
Color light,DBSTAR,Nova,Linsn
|
|
Ambient Temperature |
-10°C ~ +55°C |
|
Input Signal |
RF S-Video RGB RGBHV YUVYC, etc.
|
|
Brightness Adjustment | 256 levels of each color (RGB) can be adjusted manually and 8 levels of each color can be adjusted automatically. |
♦ Production process:
1) Incoming Inspection→2)SMD→3)Plug-in
→4) Wave Soldering→5)After Welding→6)Testing
→7) Semi Finished Aging→8)Module Assembly
→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing
♦ Packaging and shipping
we can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.
we can choose the best shippment which is convenient to you!
SCXK group can give you the short delivery time and With the large production ability ,
you can feel free about this . By air ,by train, by sea?
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ FAQ:
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-10 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
