High Resolution P2.5 SMD LED Screen Indoor LED Display 3G / 4G Wireless Control

High Resolution P2.5 SMD LED Screen Indoor LED Display 3G / 4G Wireless Control

  • High Resolution P2.5 SMD LED Screen Indoor LED Display 3G / 4G Wireless Control
  • High Resolution P2.5 SMD LED Screen Indoor LED Display 3G / 4G Wireless Control
High Resolution P2.5 SMD LED Screen Indoor LED Display 3G / 4G Wireless Control
Product Details:
Place of Origin: MADE IN CHINA
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SCXK-P2.5 indoor
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: Indoor P2.5 Smd Led Display Module Size: 160mm*160mm
Tube Chip Color: Full Color Pixel Pitch: 2.5mm
Resolution: 64mm*64mm Certificate: CE FCC SGS ROSH ISO9001
High Light:

led display smd

,

smd led display

High Resolution P2.5 SMD Led Screen Indoor LED Display 3g/4g Wireless Control commercial advertising led display





Shenzhen Shichuangxinke Electronic Co.,Ltd Is a professional company in R&D, manufacture and sale of high-accuracy led display. As a national high and new tech enterprise in China, we have strong capability of R&D and production. With the over-30000- m ² highly efficient R&D centre in Shenzhen, China.



Some unique international advanced technologies are applied to production of various kinds of indoor and outdoor video display system, LED video shining letter and unique fore maintenance and rear maintenance product line, such as programmable hardware nonlinear vision correction, point-to-point control and detection, chromatic multimedia output, large scale integrated circuit and programmable ultra large scale integrated circuit and etc, so that LED display images will be clearer with more hierarchy and brighter color and products will be of environmental protection and energy saving with high luminance and long service life and excellent stability which reach international standard, have ready sale in Shenzhen, Guangzhou, Wuhan, Ningxia,Xinjiang, Neimenggu, Hong Kong, Macao, Taiwan, USA, South America, Southeast Asia and Middle East, and win great favor from

customers.



High Resolution P2.5 SMD LED Screen Indoor LED Display 3G / 4G Wireless Control 0



Product feature



1) LED: well-known international brand,with wide viewing angle ,little attenuation ,good heat dissipation, and vivid colors.

2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba, avoidable the defective

phenomena, such as dark bright, virtual light and so on.

3) Power supply: industrial-strength brand.The power maximum power resere of 20% the space , the range of voltage fluctuation is less 5%, high stability.

4) Connector: Aerial grade brands ensure the stable transmission of power and signal.

5) Easy installation





Techinical Specification of led display:

LED Module Item Parameter
Model Number P2.5-32S
Module Size 160mm*160mm
Pixel Pitch 2.5mm
Pixels Density 160000dots/m2
Pixel Configuration 1R1G1B
Package Mode SMD2121
Pixel Resolution 64 dots(W)*64 dots(H)
Max Power Consumpion 800W
Weight 0.25kg
Drive Type Constant drive
Scan Mode 1/32 scan
Port Type HUB75-A
Brightness Of White Balance ≥ 1200cd/m2
Bracket Size 160*160mm
LED Cabinet Dimension 640mm*640mm
Quanty of Module 16pcs
Pixel Per Cabinet 256*256
Best Viewing Distance 2.5M~50M
Best Viewing Distance 120°(W) 90°(H)
Temperature Storage:-20℃~+60℃
Working:-15℃~+55℃
Opration Humidity 10%-95%
Thickness 75mm
Protection Level IP43
Power Working Voltage AC220V±10%
Average Power Consumption 280W/m2
Max.Power Consumption ≤800W/m2
Control system CPU Pentium4 or above
Operation System WIN98/2000/NT/XP
Control Method Synchronization
Main technical
parameter
Driving Device Constant currentdriver IC
Refresh frequency ≥1920HZ
Grey Scale/ Colors 256levels of each color(RGB)/16.7M colors
MTBF ≥10000hours
Power Switch Automatic switch
Display Mode

800*600/1024*768



About our led displays



1. Wide application field & short ROI time:

commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media,shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen

air port LED display screen, telecommunication LED display screen system for information showing and instruction .



2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.



3. First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system



4. Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.





Methods for Quality Assurance

a. Aging

100% fully test     Condition: 72 hours with 256 gray level





b. Vibration Testing

Condition: 3-5 min up and down in 5mm range





The epistar Led chip. with SMD and DIP Technology .



we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available










The wire or wireless controll system are available .( 3g and wifi controll will be welcome)








The steer consturction is very stable for led display,and you can purchase from your local market .





The package and shippment






we can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.

we can choose the best shippment which is convenient to you!

SCXK group can give you the short delivery time and With the large production ability ,

you can feel free about this . By air ,by train, by sea?





Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.



Competitive Advantage:

1. 2 years’ warranty with free repair service

2. 24/7 Hours online Remote Support

3. Solution and PCB design

4. Free factory training

5. On site installation instruction and regular inspection

6. Small order accepted.
