Big P3.91 Concert Stage Background Led Screen Display Environment Friendly





Big P3.91 Concert Stage Background Led Screen Display Environment Friendly

Shenzhen Shichuangxinke Eletronic  Co., Ltd is a leader manufacturer of led display,who focuses on led science and technology. With the concept of technological cooperation and independent innovation, it develops a series of new products with their own intellectual property. Some unique international advanced technologies are applied to production of various kinds of indoor and outdoor video display system, LED video shining letter and unique fore maintenance and rear maintenance product line, such as programmable hardware nonlinear vision correction,



Features



Super high resolution SMD technology for intdoor LED rental displays

Point-to-point control and detection, chromatic multimedia output
Excellent color reproduction, ultimate image quality, high contrast.
Modularity & fanless design, Lightweight and slim die casting aluminum casing
Excellent grey scale, high contrast.

Large scale integrated circuit and programmable ultra large scale integrated circuit
Fast installation: Quick install locks with three steps, push-twist-fasten.

Seamless: high-precision CNC processing cabinet with precision +/- 0.05mm;





Spec

Model	Unit	P3.91
Pixel pitch	mm	3.91
Pixel resolution	pixel/m²	65410
pixel/cabinet		128dots*128dots
Pixel configuration	-	High Brightness SMD2121 3-in-1 packaged
Viewing angles	horizontal	120° at 50% brightness
	Vertical	90° at 50% brightness
kg/cabinet		7.2
Brightness	CD/m²	2500
Contrast ratio	-	1,000:1
Color temperature	K	6,500
Color processing	bit/color	12
Colors	number	10.7billion
Grayscale	steps	16,384
Best viewing distance	m	3 - 50
Refresh rate	Hz	≥1,000
Control system	-	LINSN/Nova
Life time	h	75,000 to 50% brightness down
Working voltage	-	AC220V or AC110V / 50-60 Hz
Cabinet dimension	mm	500 x 500 x 77
Aspect ratio	-	1:1
Cabinet material	-	die-casted aluminum
Protection rate	IP	43
Working temperature	°C	-15 to +55
Working humidity	RH	10% to 95%
Image source with LED video processor	-	HDMI, CVBS, YC, YUV, RGB DVI, SDI/HDSDI
Image source without video processor	-	DVI
Maximum transmitting distance	m m	<100 with network cable <2,000 with optical fiber cable
Cabinet interfaces	-	2 signal ports, 2 power ports
Maximum per power entry	cabinets	220V power input: 18 110V power input: 9
Maintenance	-	back



♦ Production process:



1) Incoming Inspection→2)SMD→3)Plug-in

→4) Wave Soldering→5)After Welding→6)Testing

→7) Semi Finished Aging→8)Module Assembly

→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing



♦ Packaging and shipping







we can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.

we can choose the best shippment which is convenient to you!

SCXK group can give you the short delivery time and With the large production ability ,

you can feel free about this . By air ,by train, by sea?





♦ Why choose us:



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.





♦ Applications



--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.



♦ FAQ



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.
