Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P3.91 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | T/T or western Union |
| Supply Ability: | 5000sqm per month |
| Product Name: | Indoor Rental P3.91 Led Video Wall | Module Size(W * H): | 250mm*250mm |
|---|---|---|---|
| Standard: | CE/ROHS/FCC/ISO2001 | Pixel Pitch: | 3.91mm |
| Resolution(W*H): | 64dots*64dots | Leds: | Kinglight2121 |
| High Light: | indoor led display screen,indoor led billboard |
||
Shenzhen SCXK Electronic Co., Ltd. is a professional and integrated manufactory of R&D different kinds of LED display products since 2005. We started from LEDs encapsulation, more than 10 years experience in LED industry. As a high-tech enterprise engaged in producing LED advertising screen, traffic sign, mobile screen, rental screen, front service screen, LED curtain/Grid display, Apple style LED advertising sign, LED outdoor single color, dual color and full color modules, some creative products such as curved and column display etc.
" To be honest , customer comes first ,humen-oriented and humonious development",is our culture principle . Our company introduces and absorbs both new knowledge and technology positively ;improving and promoting service quality constantly ;targets at satisfying the demands of consumers in an all-round way,and sticks at working a better prospects for LED display industry.
| Product model | P3.91S |
| Module size | 250mm*250mm |
| Pixel pitch | 3.91mm |
| Pixel density | 65410dots/m2 |
| Pixel configuration | smd 2121 |
| Module resolution | 64dots(W)*64dots(H) |
| Maximum power consumption | 700W |
| Module thickness | 13.5mm |
| Module weight | 0.18kg |
| Driving method | Constant current driving |
| Scan mode | 1/16 scan |
| Interface type | HUB75-A |
| Brightness | ≥1000cd/m2 |
| The specifications of cabinet | |
| Cabinet size | 500mm*500mm |
| Module quantity | 4pcs |
| Power supply | 5V/40A *2pcs |
| Cabinet resolution | 128*128dots |
| Optimal viewing distance | 4m~20m |
| Optimal viewing angle | 160°(W) 120°(H) |
| Temperature | Storage:-35ºC~+85ºC Working:-20ºC~+50ºC |
| System operating humility | 10%-95% |
| The specifications of power supply | |
| Operating voltage | AC220V±10% |
| Average power consumption | 220W/ |
| Maximum power consumption | ≤160W/ |
| Current | ≤20mA(single LED) |
| The specifications of control system | |
| Computer | Pentium4 or above |
| Operating system | WIN98/2000/NT/XP |
| Control model | Synchronization control |
| The specifications of the main technical parameters | |
| Driving device | Constant current driving |
| Refresh rate | ≥400Hz |
| Grey scale | RGB each 256 grade, can display 16.7M colors |
| MTBF | ≥9000hours |
| Power switch | Automatic switch |
| Display mode | 800*600/1024*768 |
Products Feature:
1. Equipped with intelligent lighting equipment and adaptive adjustment of environment, will not affect by the ambient light strong display effect and environmental protection and energy saving for Rental LED Display.
2. Any direction, any size, any shape can be jointed presenting perfect seamless visual effect;
3. Leasing LED video screen with die-casting aluminum frame design, screen is super light and thin, saving space and costs, fashionable and beautiful;Adopting die-casting aluminum improves the heat dispersion, prolonging the lifetime of the led display.
The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available
The wire or wireless controll system are available .( 3g and wifi controll will be welcome)
Payment and delivery
1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ FAQ
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
