Name: P5 Outdoor LED Display 5mm Pixel Pitch IP65 Waterproof
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P5
Price: 471.00 USD
Availability: InStock

Home Products Stadium LED Display

P5 Outdoor LED Display 5mm Pixel Pitch IP65 Waterproof

Product Details:

Place of Origin:	ShenZhen China
Brand Name:	SCXK
Certification:	CE/ROHS/FCC/ISO/CB
Model Number:	P5

Payment & Shipping Terms:

Minimum Order Quantity:	5 pcs
Price:	371$-571$
Packaging Details:	flight case, wooden case, carton, it is up to you.
Delivery Time:	7-15 working days after receive your payment
Payment Terms:	T/T,Western Union,MoneyGram
Supply Ability:	5000sqm per month

Contact Now

Detailed Product Description

Pixel Pitch:	5mm	Tube Chip Color:	Full Color
Led Type:	SMD2727/3535	Display Function:	Video/Text/Image
Waterproof:	Ip65	Cabinet:	Die Casting/iron
MBI:	5024	Viewing Angle:	H:160 V:140
Voltage:	DC5V	Cabinet Size:	960*960mm
Highlight:	perimeter led display , led perimeter advertising boards

Waterproof Outdoor LED Screens P5 Sport Stadium LED Perimeter Display Large Stadium

Product Specifications

Attribute	Value
Pixel Pitch	5mm
Tube Chip Color	Full color
Led Type	SMD2727/3535
Display Function	Video/Text/Image
Waterproof	IP65
Cabinet	Die casting/iron
MBI	5024
Viewing Angle	H:160° V:140°
Voltage	DC5V
Cabinet Size	960*960mm

P5 Outdoor Sports Field Large LED Advertising Billboards Video Wall Panel

High Gray Scale - Better Picture of Stadium LED Display

The Indoor LED Display is manufactured using premium quality materials sourced from reputable vendors. The final products feature supreme quality and deliver optimal outputs. High refresh rate and gray scale ensure seamless picture quality.

Product Description of Stadium LED Display

Technical Parameters

Parameter	Specification
Resolution/mm	5
Pixel configuration	1R1G1B
Pixel density/pixels/m²	40000/m²
Module resolution	32x32
Module size/mm	320x160
View distance	5-400m
Single point brightness adjust	Can be added
Single point color adjust	Can be added
White balance brightness	>5000cd/㎡
Color temperature	6500K-9500K
Horizontal view angle	120°
Vertical view angle	60°
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	(1/8)
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>5000hours
Life time	100000hours
Life-all-white(brightness halving)	50000hours
Environment temperature range	Operating temperature range: -20-45℃
Maximum power:/㎡	<800W
Average power:/㎡	<280W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Production Process

Incoming Inspection
SMD
Plug-in
Wave Soldering
After Welding
Testing
Semi Finished Aging
Module Assembly
Gluing
Finished Aging
Detection Finishing Warehousing

Packaging and Shipping

Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping options available.

Why Choose Us

Continuous Quality: With more than 10 years experience in LED display production, equipment is updated regularly. Unique standardized and modular production ensures consistent product quality.
Competitive Price: Large scale production capacity and professional production technology enable effective modular production. We promote technical innovation to reduce costs and benefit customers.
Fast Delivery: We honor promised delivery dates and implement special procedures like emergency inventory to maintain uninterrupted supply.
Perfect Service: Pre-sales: We carefully consider your requirements and recommend suitable products. After-sales: We track product usage to continuously improve our offerings.

Workshop Show

Hope we can be partners in future growth!
