P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control

P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control

  • P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control
  • P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control
  • P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control
  • P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control
P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SMD P6
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: P6mm HD Full Color Taxi Car Top LED Sign Display With WIFI 4G Control Tube Chip Color:: Full Color
Life Span:: 100000hours Certificate:: CE ROHS FCC
LED Chip:: Epistar Warranty: 5 Years
High Light:

car led message display

,

car led display board

P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control



♦ Operating Voltage DC12V


-- Power consumption : Max:800W Average:300W
-- Operating temperature : —20℃~+50℃
-- Operating humidity : 10%—95%RH
-- Life time : ≥100,000hours
-- MTBF : 5,000 hours
-- Frame frequency : >60 Hz/s
-- Operating system : Windows 2000 / Windows Xp / Windows 7

♦ Feature

1. The first level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A row material for module frame and mask

4. 4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty

8 .Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.

9 .Life time >11 years;

♦ Product specification


Lamp size 2727
Resolution/mm 6
Pixel configuration RGB  3 in 1
Pixel density/pixels/m² 27778/m²
Module resolution 32*32
Module size/mm 192*192MM
View distance ≥4m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 14 bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode constant driving static
Frame rate 60Hz
Refresh frequency >2500Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted

255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡ <800W
Average power:/㎡ <300W
Self-check technology

LED spot self-check, communications check, power check,

temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,

send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control 0


♦ Production process:

1) Incoming Inspection→2) SMD→3) Plug-in

→4) Wave Soldering→5) After Welding→6) Testing

→7) Semi Finished Aging→8) Module Assembly

→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing



♦ Packaging and shipping

Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.



♦ Why choose us:

Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.
