High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade

High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade

    • High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade
    • High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade
    • High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade
    • High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade
    • High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade
  • High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade

    Product Details:

    Place of Origin: China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/SGS
    Model Number: TL10.41

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: negotiation
    Packaging Details: Packed in wooden case and flight case for outer packing
    Delivery Time: 10 working days after received your payment
    Payment Terms: T/T or western Union
    Supply Ability: 5,000/ Sq m per month
    Contact Now
    Detailed Product Description
    Product Name: TRANSPARENT Led Screen Cabinet Size: 500mm*1000mm*80mm
    Standard: CE/ROHS/FCC/ISO9001 Tube Chip Color: Full Color
    Pixel Pitch: 10.41 Mm Resolution(W*H): 48dots*96dots
    Led Lamp: Nationstar Led Chip: Epistar

    p10.41 full color high transparent LED Screen for Shopping mall glass facade



    Advance of Die-casting transparent led screen



    1) LED: well-known international brand, with wide viewing angle, high brightness, little attenuation, good heat dissipation, and vivid colors.



    2) Driving display: famous brands such as, Taiwan MBI, chenkse Chenkse, avoidable the defective phenomena, such as dark bright, virtual light and so on.



    3) Power supply: industrial-strength brand. The power t maximum power reserve of 20% the space, the range of voltage fluctuation is less 5%, high stability.



    4) Connector: Aerial grade brands ensure the stable transmission of power and signal.



    5) PCB Board: adopt 4-layer design.



    6) Easy installation:100 pieces of cabinets' installation can be finished in one hour by one person. The replacement of any cabinet can be done within 50 seconds.





    Shenzhen Shichuangxinke Electronics co., Ltd. is a best global supplier of LED display total solution, which is specializing in the R&A, production and market of LED display and LED lighting products. We are equipped with full series of automatic production line, including advanced manufacturing equipment and perfect testing device, which guarantee a monthly capacity of 800 square meters LED display.
    Our R&A team possesses 14% of total staff and most of the developing engineers with more than10 years

    experience in LED industry. Their market-oriented innovation keeps our leading position in this industry.

    Quality is our company philosophy. We Insists to offer high quality and best service for our client, Our products has been approved by CCC,CE,FCC,Rohs and etc.Moreover, our products are exported to oversea markets around European countries and middle east area, such as the USA, Dubai, Russia, Sweden, Turkey, Poland,France, Israel, Lebanon, Spain and so on.



    LED Module Pixel Pitch 10.41mm
    LED Cabinet Cabinet Size 500mmX1000mm*80mm
    Cabinet Resolution 48pixels *96pixels
    Cabinets Material Die casting Aluminum Cabinet
    LED Display Pixel Density 9216 pixels/sq.m
    Drive IC MBI5124
    Power Supply Series connection
    Brightness >4200cd/sqm
    Display Color 16.7million
    Viewing Angle 110°(Horizontal),50°(Vertical)
    Best Viewing Distance 5m~100m
    Max Power Consumption 530w/sqm
    Average Power Consumption 212 w/sq.m
    Refresh Rate 16bit ≥2880; 14bit ≥4800; 10bit ≥9600
    Input Voltage AC220V/50H or AC110V/60H
    Output Voltage DC5V 60A/80A
    Grey Scale Levels 16bit
    Installation Way Hanging / Stacking / Permanent Installation
    Drive IC Taiwan MBI/Domestic High refresh rate IC(Optional)
    Life-span 100,000 hours
    Protection Level IP30
    Failure percentage of leds less than 0.0003
    Working Temperature -10~40°C
    Drive Mode 1/4 scan constant current
    Working Humidity 10%~90%
    LED Encapsulation Self-development Side view LED lamp
    Eliminate Ghost Line Yes
    Working Voltage DC5V
    weight <6.2kg
    Control method Synchronization & Asynchronization
    Control System Control System Mooncell/ Nova/ Linsn(Optional)
    Software LED Studio
    Input Signal DVI/HDMI/DP
    PC Operating system Microsoft Windows 7, 98, 2000, XP and Vist





    High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade

    High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade
    High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade

    led screen feature



    1.Wide application field & short ROI time:

    commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media,floor tile screen ect.

    shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen

    air port LED display screen, telecommunication LED display screen system for information showing and instruction .



    2. High Contrast ratio: 4000:1
    Which is a very high level to ensure a vivid image of our LED display screen system.


    3. First-class LED chip:
    Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system



    4. Clear vivid image quality:
    Even in direct full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's

    investment.



    Methods for Quality Assurance



    a. Aging testing :100% fully test Condition: 72 hours with 256 gray level

    b. Vibration Testing:Condition: 3-5 min up and down in 5mm range




    Payment and delivery

    1) T/T, 30% deposit, 70% before shippment.
    2) 100% Western Union in advance.





    ♦ Why choose us:



    Continues Quality

    With more than 10 years experience in led display producing,equipments are updated regularly.What’s

    more,unique standardized and module production ensure our products continuous quality.



    Competitive Price

    With large scale production capacity and professional production technology,our company have built

    effective modular production.We always stick to promote the technical innovation and reduce cost to

    benefit customers.



    Fast Delivery

    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

    inventory will be used to maintain your uninterrupted supply of the products.



    Perfect Service

    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

    you.

    After-sales:We will track the products usage and then constantly perfect our products.



    High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade

    High Transparent LED Screen P10.41 Full Color For Shopping Mall Glass Facade





    ♦ FAQ



    What kind of payment terms you can accept ?

    We can accept T/T and Western Union.



    What about your Led Display quality ?

    Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

    our products continuity.



    What is your delivery time ?

    Within 7-35 days according to your area and quantity.



    Is your LED display competitive ?

    Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

    our led display’s competitiveness.
