SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet

SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet

  • SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet
  • SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet
SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: 1 sqm
Price: negotiation
Packaging Details: wooden case
Delivery Time: 5-8 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Module Size: 192x192mm Pixels Density: 27778 Pixels/sqm
Mode Driving: 1/8 Scan Cabinet Material: Ironed Steel Cabinet
Cabinet Size: Customoized LED Lamp: SMD 3535
Pixel Configuration: 1r1g1b Warranty: 3 Years
High Light:

full color outdoor led display

,

outdoor full color led screen

Outdoor LED Video Wall P5 LED Screen High Resolution 3840hz 16 Scan Driving

Product Description:

slim display cabinet for stage show/led display screen indoor for events/led video wall for concert

Application of LED display screen:

LED display,also called led screen, led video wall, or led sign, with its unique advantages,has gradually replaced the traditional billboards, light boxes,etc. LED display advertising has become a new force in the media industry.

Traditional advertising can only show pictures, But LED display/led video wall/led screen can perfect combine text, pictures, video, and sound with high resolution,high brightness and full color! LED display Advertising screen can easily attract the attention of pedestrians,and also are easy to remember,which can generate greater advertising effectiveness.

Led display screen now are widely applied in media advertising, transportantion,Security,
Real estate and Stage show background.


Specification

Module Parameter:

Pixel pitch 6mm
Pixel configuration 1R1G1B
LED type 3-in-1 SMD 3535
Module size 192*192mm
Module weight 0.4kg
Module resolution 32*32dots
Module quantity per cabinet 8pcs



Cabinet Parameter:

Cabinet size 960x960mm
Cabinet material ironed steel cabinet
Cabinet weight 32.5kg
Cabinet resolution 96:96 dots
Ingress protection Front/Rear IP65/IP54



Whole Screen Parameter

Pixel density 27778 dots/m²
Brightness ≥6000 cd/m²
Viewing angle H≥120° V≥120°
Min.viewing distance 6m
Max.power consumption 850W/m²
Avg.power consumption 300 W/m²
Working voltage 110~220VAC±15%
Interface HUB75
Colors 16.7millon colors
Gray level 14-16bits
Frame frequency ≥60frames/s
Refresh rate ≥600Hz
MTBF ≥10000 hours
Lifespan ≥50000 hours
Protective function

Over-heat/Over-load /Power-down /Power-leakage

/Lightning-protection etc.

Operating temperature -10℃ ~ +40℃
Operating humidity 10-80% no condensation
Storage temperature -20℃ ~ +60℃
Storage humidity 10-85% no condensation



Control System Parameter:

Video signal (with video processor) AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature Adjustable by software
Brightness level 256 levels, automatic adjustment by software
Control way Computer, video-synchronous, real-time, off-line, wireless, internet etc.



Product item
SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet 0
SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet 1

Company profile
Shenzhen SCXK Electronic Co.,Ltd has the standard new factory, and about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led single dual color display, led indoor full color display; led outdoor full color display, led wireless car used screen etc. It can be used on the shopping more, bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi and so on.. We adapt many methods and very good after-sell service to sell our product all over the word. Whenever and wherever we are, we always take the principle that is: professional makes good quality, good price product market to provide perfect product and service for our customers.
SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet 2


Certificate
SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet 3


Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
SCXK Installation P6 Led Video Wall Screen Waterproof Fixed Ironed Steel Cabinet 4


Buying Guides
In order to offer you a suitable solution, please follow the guides bellowing :
1, star effect or video effect which you need.
2,Dimension (Width and Height)
3,Location of installation. (picture is best)
4,Purpose. ( what are you going to do with the LED Curtain)


After-Sale Service
1. One year warranty , Lifetime free maintenance.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on
6. Special service for big project, such as stadium, exhibitions, squares and so on.


FQA
Q1. Can I have a sample order for Indoor Full color LED Advertising Display?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Our average Production time is 7-10 days, after receiving the deposit.we will try our best to meet your demands
Q3. Do you have any MOQ limit for Indoor Full color LED Advertising Display order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for Indoor Full color LED Advertising Display?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on Indoor Full color LED Advertising Display product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q:Why Choose us?
We are direct factory manufacturer for led display, so quick delivery is no problem.
More professional, best service,100% QC inspection before shipment.
