IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm

IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm

  • IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm
  • IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm
  • IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm
IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P4
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: negotiation
Packaging Details: wooden case or flight case are available.
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 4mm Pixel Configuration: 1R1G1B
Pixel Density: 62500dots/m2 Module Size: 256x128mm
Driving Mode: 1/16 Scan Brightness: ≥1500cd/m2
Cabinet Size: 768x768mm Cabinet Material: Simeple Ironed Steel Cabinet
Warranty: 3 Year
High Light:

indoor led display screen

,

indoor led billboard

Indoor led screen p4 display advertise video wall simple ironed steel cabinet 768x768mm

LED display features:
1. the brightness is very high: the brightness of the outdoor LED display is ≥6500cd/sqm, which is the only large display terminal that can be used outdoor all day long; the brightness of the indoor LED display is ≥ 1500cd/sqm.
2, long life: LED life is up to 100,000 hours (ten years) or more, this parameter generally refers to the design life.
3, the viewing angle is large: the indoor viewing angle can be greater than 160 degrees, and the outdoor viewing angle can be greater than 120 degrees. The size of the viewing angle depends on the shape of the LED light emitting diode.
4, the screen area can be as small as less than one square meter, and as large as several hundred, thousands of square meters;
5, easy to interface with the computer, support software rich.


Module Parameter:

Pixel pitch4mm
Pixel configuration1R1G1B
LED type3-in-1 SMD 2121
Module size256x128mm
Module resolution64*64dots


Cabinet Parameter:

Cabinet size768x768mm
Cabinet materialsimple ironed steel cabinet
Cabinet weight12.5kg
Ingress protectionFront/Rear IP65/IP54


Whole Screen Parameter

Pixel density62500 dots/m²
Brightness≥1500 cd/m²
Viewing angleH≥140° V≥140°
Min.viewing distance4m
Max.power consumption750W/m²
Avg.power consumption300W/m²
Working voltage110~220VAC±15%
InterfaceHUB75
Colors16.7millon colors
Gray level14-16bits
Frame frequency>1000frames
Refresh rate>1920Hz
MTBF≥100,000 hours
Lifespan≥100,000 hours
Operating temperature-10℃ ~ +40℃
Storage temperature-20℃ ~ +60℃


Control System Parameter:

Video signal (with video processor)AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperatureAdjustable by software
Brightness level256 levels, automatic adjustment by software
Control wayComputer, video-synchronous, real-time, off-line, wireless, internet etc.


Cabinet photo
IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm 0
 IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm 1

Company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm 2
Certificate
IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm 3
Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm 4
IP65/IP54 P4 Advertising Led Display Video Wall Simple Ironed Steel Cabinet 768x768mm 5


Our service
Warranty
1.We guaratee all our display, modules, spare parts for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3.After warranty, we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once
when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you antil it recovers well by remote control!
Installation
1.We can assist the training and technical support for the customer in the factory, if the customer require so.
2.We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need.
