LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain

LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain

  • LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain
  • LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain
  • LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain
  • LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain
  • LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain
  • LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain
LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCXK
Certification: CE,ISO,FCC,UL
Model Number: SCXK-P4.81
Payment & Shipping Terms:
Minimum Order Quantity: customized
Price: 500-1120USD/sqm
Packaging Details: Wooden and flight cases.
Delivery Time: 12-15working days.
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 5000Sqm/month
Contact Now
Detailed Product Description
Application Place: Indoor Pixel Pitch: 4.81mm
Cabinet Size: 500*500mm Cabinet Material: Aluminum
Scan Mode: 1/13 Brightness: 6000cd/sqm
Certificate: CE,ISO,FCC,UL
High Light:

flexible led stage screens

,

flexible led display



LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain



Introduction of us and products:



1.Obtain a number of national certificates and international certificates;

2.The mask is made of high density alkaline PC material.

   The surface is treated by grinding technology, which is skid-proof and dazzling-proof.

3.Anti-sharp and blunt, anti-scratch mask design, the display screen is guaranteed to be used for a long time;

4.Using advanced glue filling technology, with waterproof washer, perfectly achieve dust, shock and waterproof;

5.Anti-uv properties, even after years of direct solar radiation, can still maintain the primary color;

6.Professional positioning hole design ensures that the screen does not move;

7.The floor drag installation is flexible, fast, without any auxiliary tools to ensure the flat surface of the screen;

8.Professional circuit design, equipped with aircraft plug connectors, high and low temperature,

   non-destructive transmission, free of exposed wiring, safe and fast;

9.High precision, uniform distribution of grilles, strong load-bearing capacity, 2 tons per square meter;

10.Human interactive induction screen can realize human-computer interaction function;



Specifications :



P4.81 Flexible Led
Resolution/mm 4.81
Pixel configuration 1R1G1B
Pixel density/pixels/m² 43222/square meter
Module resolution 52x52
Module size/mm 250x250
White balance brightness 1000cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/13 SCANNING
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%

LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain 0

LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain 1

LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain 2



Shipping and package:

We use wooden and flight cases to package the goods,and for free;

We have our own freight forwarding,and the cost can be low than others,

also,if you want to use yourself,it's ok.

LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain 3





Payment:

1.We accept T/T and Western Union;

2.Delivery time is about 12-15 working days after receiving your down payment;

3.We will provide you good service,not only the Pre sale,also the in sale and after sale;

4.Any questions can contact our sales engineer;

LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain 4





FAQ:

Q1: What's the warranty of your LED Display Screen ?

A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps.

Q2: What about your pre-sale service and post-sale service?

A2: For pre-sale service: We have a professional sales team and 13 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the screens, and change the broken modules with spare parts.
Also, we can send technicians to your country to solve problems. Mostly, our led display will not have big problems within warranty time!

Q3: Whats your payment term? How long it takes to delivery?

A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery.
Our average Production time is 16 days, after receiving the deposit.

Q4: What's the control system?

A4: For synchronization control: We use Nova, Linsn Or Colorlight control system.
For asynchronous control: We use ONBON or XIXUN control system.

Q5: How can you ensure the led display product quality?

A5: Our led display screen quality is our core competence, for 8 years, what we rely on.
We have each standard process to make quality products.
If any quality failures within warranty time, we will refund you .



Welcome to visit our website and inquire us more info,waiting for you all the time!!!
