Place of Origin: | China(Mainland) |
Brand Name: | SCXK |
Certification: | CE,ISO,FCC,UL |
Model Number: | SCXK-P4.81 |
Minimum Order Quantity: | customized |
---|---|
Price: | 500-1120USD/sqm |
Packaging Details: | Wooden and flight cases. |
Delivery Time: | 12-15working days. |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 5000Sqm/month |
Application Place: | Indoor | Pixel Pitch: | 4.81mm |
---|---|---|---|
Cabinet Size: | 500*500mm | Cabinet Material: | Aluminum |
Scan Mode: | 1/13 | Brightness: | 6000cd/sqm |
Certificate: | CE,ISO,FCC,UL | ||
High Light: | flexible led stage screens,flexible led display |
LED Stage Curtain Screen P4.81 For Live Events,Dance Floor Led Stage Background Curtain
Introduction of us and products:
1.Obtain a number of national certificates and international certificates;
2.The mask is made of high density alkaline PC material.
The surface is treated by grinding technology, which is skid-proof and dazzling-proof.
3.Anti-sharp and blunt, anti-scratch mask design, the display screen is guaranteed to be used for a long time;
4.Using advanced glue filling technology, with waterproof washer, perfectly achieve dust, shock and waterproof;
5.Anti-uv properties, even after years of direct solar radiation, can still maintain the primary color;
6.Professional positioning hole design ensures that the screen does not move;
7.The floor drag installation is flexible, fast, without any auxiliary tools to ensure the flat surface of the screen;
8.Professional circuit design, equipped with aircraft plug connectors, high and low temperature,
non-destructive transmission, free of exposed wiring, safe and fast;
9.High precision, uniform distribution of grilles, strong load-bearing capacity, 2 tons per square meter;
10.Human interactive induction screen can realize human-computer interaction function;
Specifications :
P4.81 Flexible Led | |||||
Resolution/mm | 4.81 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 43222/square meter | ||||
Module resolution | 52x52 | ||||
Module size/mm | 250x250 | ||||
White balance brightness | 1000cd/square meter | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/13 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | >3000Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
Shipping and package:
We use wooden and flight cases to package the goods,and for free;
We have our own freight forwarding,and the cost can be low than others,
also,if you want to use yourself,it's ok.
Payment:
1.We accept T/T and Western Union;
2.Delivery time is about 12-15 working days after receiving your down payment;
3.We will provide you good service,not only the Pre sale,also the in sale and after sale;
4.Any questions can contact our sales engineer;
FAQ:
Q1: What's the warranty of your LED Display Screen ? A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps. |
Q2: What about your pre-sale service and post-sale service? A2: For pre-sale service: We have a professional sales team and 13 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project! |
Q3: Whats your payment term? How long it takes to delivery? A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery. |
Q4: What's the control system? A4: For synchronization control: We use Nova, Linsn Or Colorlight control system. |
Q5: How can you ensure the led display product quality? A5: Our led display screen quality is our core competence, for 8 years, what we rely on. |
Welcome to visit our website and inquire us more info,waiting for you all the time!!!
Contact Person: Lillian lin
Tel: +8613226123209
