High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby

High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby

  • High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby
  • High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby
  • High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby
  • High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby
  • High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby
  • High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby
High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P3
Payment & Shipping Terms:
Minimum Order Quantity: 1sqm
Price: negotiation
Packaging Details: wooden case or flight case are available.
Delivery Time: 7-15 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Pixel Pitch: 5mm Pixel Configuration: 1R1G1B
Pixel Density: 111111dots/m2 Module Size: 192x192mm
Driving Mode: 1/16 Scan Brightness: ≥1500cd/m2
Cabinet Size: 576x576mm Cabinet Material: Die Casting Aluminum Cabinet
Warranty: 3 Year
High Light:

led stage display

,

stage background led screen

High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby



As you know, the led technology has changed the world rapidly. As a good application of this technology, led screen has been used universally in different areas. They bring us wonderful visual and auditory experience, Making the world colorful and beautiful.
Shenzhen ShiChuangXinKe Electronics Co.,Ltd, as a professional led display manufacturer, we provide personalized led display solutions for your case with reasonable price and guaranteed quality ! Our website:
www.scxled.cn We are ready all the time, Enjoying your visiting and welcome to contact us !



Unit Module Specifications
Item P3
Pixel Pitch 3 mm
Pixel Configuration 3in1 (1R1PG1B)
Module Size(MM) 192*192
Module Resolution(Dots) 64*64
Module Weight(Kg) 0.3
Package LED Mode SMD2121
Max Power(Watt) 21
Pixel Density(Dots/SQM) 111'111
Driving Method Constant Current Driving
Scan Method(Scan) 1/32
Interface Way HUB 75
Brightness(CD/SQM) ≥ 1500
Safety Standard CCC,FCC,ROHS,TUV,CE,ETL,UL,BIS.....
Unit Cabinet Specifications
Cabinet Size(MM) 576*576
Cabinet Composing(PCS) 9
Power Supply Mode(Per Cabinet) 5V60A
Cabinet Resolution(Dots) 192*192
Optimal Viewing Distance(M) 3-300
Optimal Viewing Angle Horizontal angle: 160 degree; Vertical angle: 140 degree
Environment Temperature Storage: -40 degree ~ +85 degree; Work: -20 degree ~ +60 degree
Relative Humidity 10% ~ 95%
Power Supply Specifications
Operating Voltage AC:100V~120V AC:220~240V
Average Power(W/SQM) 150-350
Max Power Consumption(W/SQM) ≤ 800
Current ≤ 20mA (single LED)
Control System Specifications
Computer Pentium4 or above P4 or above
Operate System Win7-11/2000/NT/XP
Control Mode Synchronization with PC
Main Technical Parameter Specifications
Driving Device Constant Current Driving
Refresh Rate ≥ 1900-3840Hz
Gray/Color RGB each 256 grade, can display 16.7color
Lifespan ≥ 100000hours
Power Switch RGX Automatic Switch
Display Mode 2048*10241024*7681280*960mm
For more information please contact our sales.



Die Casting Aluminum Cabinet Details, This Cabinet Is Light, Thin And Is Easy To Intall For

Different Events.

High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby 0

High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby 1

High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby 2

Company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby 3
Certificate
High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby 4
Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby 5
High refresh rate 3840 hz indoor P3 Led Screen Display for hall lobby 6


Our service
Warranty
1.We guaratee all our display, modules, spare parts for TWO years.
2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
3.After warranty, we also can offer you the parts for replacement at our bottom price.
4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once
when we get it and offer you a good solution to solve the problem.
5.We also could solve problems for you antil it recovers well by remote control!
Installation
1.We can assist the training and technical support for the customer in the factory, if the customer require so.
2.We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need.
