Full Color Display SMD LED Screen P10 5500 Nits Outdoor Fixed Installation

Full Color Display SMD LED Screen P10 5500 Nits Outdoor Fixed Installation

  • Full Color Display SMD LED Screen P10 5500 Nits Outdoor Fixed Installation
  • Full Color Display SMD LED Screen P10 5500 Nits Outdoor Fixed Installation
  • Full Color Display SMD LED Screen P10 5500 Nits Outdoor Fixed Installation
Full Color Display SMD LED Screen P10 5500 Nits Outdoor Fixed Installation
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCX
Certification: FCC,ISO,CE
Model Number: SCX-P10
Payment & Shipping Terms:
Minimum Order Quantity: 5sqm
Price: 399-511USD/sqm
Packaging Details: Carton,wooden and flight cases.
Delivery Time: 12-15 working days.
Payment Terms: T/T, Western Union
Supply Ability: 5000sqm/month
Contact Now
Detailed Product Description
Installation: Outdoor Usage: Fixed
Pixel Pitch: 10mm Module Size: 320*160mm
Cabinet Size: 960*960mm Material: Iron
Brightness: 5500nits Scan Mode: 1/4
Pixel Density: 10000dots/sqm Warranty: 2 Years
High Light:

led display smd

,

smd led display

SMD LED Screen P10 Outdoor Fixed Installation Full Color Display

Fixed Screen---It is the normal type,if you install the display in one place and don't need to
move to other places,then you can choose this one,for the price is lower than the rental series;
its material is iron,so the weight is much more higher than the aluminum,if you think the heavy
weight will cost much shipping,then we also have the simple type-without backdoor,and the price
will be cheaper;anyway,diffferent usage should choose the suitable style,tell us all your requirements,
and we will give you the best proaessional advice according to our enginner's experience.

Full Color Display SMD LED Screen P10 5500 Nits Outdoor Fixed Installation 0

Product description:


Resolution/mm 10
Pixel configuration 1R1G1B
Pixel density/pixels/m² 10000dots/square meter
Module resolution 32x16
Module size/mm 320x160
View distance 10-100m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness 5500cd/square meter
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode 1/4
Frame rate 60Hz
Refresh frequency 1200Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Maximum power:/square meter <850W
Average power:/square meter <280W
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%
