Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | CHINA |
| Brand Name: | SCXK |
| Certification: | CB/CE/ROHS/FCC/ISO/UL |
| Model Number: | SMD P2.5 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 sqm month |
| High Light: | led screen module,led sign module |
||
|---|---|---|---|
and peripheral products R & D, production, sales and service in one. company spent more than 10 years of time, carefully built a professional platform for a modern enterprise,selling according to market demand, industrial chain business model, forming a complete advanced system of production,we are one of the fastest development high-tech enterprises in domestic industry and the world's.
We rely on advanced management mode, strong R & D and excellent technical ability and rich in raw materials supplier chain, to produce high quality products.
| Technical parameter | |
| Pixel pitch (mm) | 2.5 |
| Cabinet size (mm) | 480*480 |
| Brightness (nit) | 2500 |
| Module size (mm) | 160*160 |
| Pixel configuration (R,G,B) | 1,1,1 |
| Pixel matrix per module (dot) | 64*32 |
| Pixel (dot/s.q.m) | 160000 |
| Viewing distance (Min) (m) | 1.5-150 |
| Gray scale (level) | 4096 |
| Refresh frequency (Hz) | 800 |
| Input power (max/avg) | 800/300 |
| Viewing angle-H (deg.) | 120 (+60/-60) |
| Viewing angle-V (deg.) | 60 (+30/-30) |
| Blind spot rate | <1/10000 |
| Color temperature (K) | 6500 |
| Ingress protection (front/rear) | IP43 |
| Input voltage (AC) | 110 ~ 240 |
| Input power frequency (Hz) | 50 or 60 |
| Signal input format (with video processor) | AV, S-Video, VGA, DVI, YPbPr,HDMI, SDI |
1) Professional Manufacturer of led display
2) Easy installation
3) Factory Price & Best Quality
4) Accept Any size of led display
5) Fast Delivery
6) Regular items in Stocks
7) We promise all inquiry and emails will get our reply within 12 hours.
The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available
The wire or wireless controll system are available .( 3g and wifi controll will be welcome)
Our Service
1)Training after order
After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment
2) Installation and debugging
BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.
3) Warranty
Warranty: 2 years warranty, lifetime maintenance
Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.
4) Maintenance
Maintenance principles: response in time, solve problems asap and ensure the use.
Maintenance period: In the maintenance period of the led display body, free of all maintenance charges
After maintenance period, only charge the material cost and labor cost.
Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.
Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6, Small order accepted.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
