P4.81 P3.91 Stage Background LED Display , LED Outdoor Advertising Screens Waterproof

P4.81 P3.91 Stage Background LED Display , LED Outdoor Advertising Screens Waterproof

P4.81 P3.91 Stage Background LED Display , LED Outdoor Advertising Screens Waterproof
P4.81 P3.91 Stage Background LED Display , LED Outdoor Advertising Screens Waterproof
P4.81 P3.91 Stage Background LED Display , LED Outdoor Advertising Screens Waterproof
Product Details:
Place of Origin: China
Brand Name: SCX
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SMD P4.81
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: P4.81 P3.91 Outdoor Stage Event Led Screens Flexible Backdrop Screen For Stage Application: Outdoor Waterproof
Cabinet Material: Aluminum Continuous Working Hours: Over 72 Hours
Scatter OOC Point: <0.01% Continuous OOC Point: None
High Light:

led stage display

,

stage background led screen

P4.81 p3.91 Outdoor stage event led screens flexible backdrop screen for stage





Features

Outdoor Rental LED Display

Pitch: 3.91/ 4.81 /5.95mm

led module Size: 500x125mm

Cabinet size: 500X500mm, 500X1000mm optional



Service

1) Reply your enquiry of led display in 24 working hours.

2) Experienced staffs answer all your query in fluent English,Spanish,French,etc

3) Customized design is available,OEM & ODM are welcomed.
4) Exclusive and unique solution can be provided to our customer by our well trained and professional engineers and staffs.
5) Special discount and protection of sales area provided to our distributor.
6) Warmly welcome your visit in our company if available.
7) Warranty: 24 months, a little investment for longer warranty time.


Product specification

SMD P4.81

Lamp size 2727
Resolution/mm 4.81
Pixel configuration RGB  3 in 1
Pixel density/pixels/m² 43222/m²
Module resolution 64x64
Module size/mm 250x250
View distance ≥2m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >8000cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 14 bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
Driving mode Constant driving current
Scanning mode 1/8
Frame rate 60Hz
Refresh frequency >4200Hz
Control mode Computer synchronous
Brightness adjusted range

Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss

Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
Maximum power:/㎡ <1000W
Average power:/㎡ <280W
Self-check technology

LED spot self-check, communications check, power check,
temperature monitor(need customization)

Remote monitoring

Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)

Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%



P4.81 P3.91 Stage Background LED Display , LED Outdoor Advertising Screens Waterproof 0



Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

Features
1. Seamless --- precision cabinet, light weight and more durable.
2. Quality LEDs --- with wide viewing angle to ensure vivid and sharp images and video.
3. High refresh rate and high gray scale --- to ensure color consistency and better images


Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.



Our team will be forever here to offer you full supports !!!
