P6 SMD Outdoor RGB LED Display 6000cd Brightness With Humanized Operating Interface

P6 SMD Outdoor RGB LED Display 6000cd Brightness With Humanized Operating Interface

    • P6 SMD Outdoor RGB LED Display 6000cd Brightness With Humanized Operating Interface
    • P6 SMD Outdoor RGB LED Display 6000cd Brightness With Humanized Operating Interface
    • P6 SMD Outdoor RGB LED Display 6000cd Brightness With Humanized Operating Interface
  • P6 SMD Outdoor RGB LED Display 6000cd Brightness With Humanized Operating Interface

    Product Details:

    Place of Origin: CHINA
    Brand Name: SCXK
    Certification: CB/CE/ROHS/FCC/ISO/UL
    Model Number: SCXK- P6

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: negotiation
    Packaging Details: wooden case,flight case,it is up to you.
    Delivery Time: 7-10 working days
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 5000 sqm month
    Contact Now
    Detailed Product Description
    Module Size:: 192mm*192mm Module Resolution:: 32*32
    Driving Mode:: 1/8 LED Size:: SMD 3535
    Brightness:: 6000cd Protection Level: IP65
    Pixel Density:: 27778 Dots/sqm

    Excellent Quality High Resolution P6 SMD Outdoor Full Color LED Advertising Display Screen 32*32mm Module Resolution





    Production Description



    1. Lightweight. Convenient in transporting and installing and saving labor cost, suitable for flow shows.
    2. Nice appearance and simple structures.
    3. Jointed correctly, being installed and dismounted by one person without tool.
    4. Humanized operating interface with breakdown indicator lights, easy to maintain.
    5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.



    ♦ Specifications

    1 SMD 3521 led display
    2 Supper refresh rate
    3 Supper energy saving system
    4 High brightness



    Part No. P6
    Module Size 192*192mm
    Module Resolution 32*32
    LED Encapsulation 1R1G1B
    Pixel Density 27778 dots/sqm
    Cabinet Size 960*768mm
    Pixel Pitch 6 mm
    LED Size SMD 3535
    Driving Mode 1/8
    Brightness 8000cd
    Contrast ≥3000:1
    Display Color 1.07 billion
    View Angle 120° degree Horizontal & 60° degree Vertical110
    Brightness Adjustment 0-100% 8 levels
    Operation Power 220V 60HZ
    Max Power Consumption 750 w
    Average Power Consumption 280 w
    Frame Update Frequency 100hz
    Screen Refresh Frequency 480hz
    Gamma Correction (-0.5—5.0)
    Operating Temp. - 10° —+55° Celcius degree
    Operating Humidity 10 - 90 % RH
    Operating Life 100,000 Hours
    MTBF 5000 Hours
    Protection Level IP65
    Out of Control Pixel Rate 0.01%
    Input Signal Support Composite, S-Video,Component,VGA, DVI,HDMI,SDI,HD_SDI
    Control Distance UTP CAT5E:100m; Multi-mode Fiber:500m;Single-mode Fiber:10km
    Support VGA Mode 800 x 600, 1024 x 768, 1280 x 1024, 1600 x 1200,
    Brightness Correction Dot by Dot,module by module, cabinet by cabinet
    Control Mode Synchronous display with control PC by DVI



    ♦ Applications



    --- Outdoor and indoor advertising, digital billboards, advertising companies
    --- Sports halls, fields, playgrounds,school church
    --- Airports, bus stations and railway passenger terminals.
    --- Facades of shopping malls, department stores, banks and car dealerships.
    --- Architecture and social projects, information systems in cities.
    --- Show-business, concerts, festivals, motor shows and other public events.



    Production process:

    1) Incoming Inspection→2)SMD→3)Plug-in

    →4) Wave Soldering→5)After Welding→6)Testing

    →7) Semi Finished Aging→8)Module Assembly

    →9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing



    Packaging and Shipping



    Wooden case or flight case package are available.

    Shipping by sea,air or DHL,multiple shipping ways for your choice.



    Why choose us:



    Continues Quality

    With more than 10 years experience in led display producing,equipments are updated regularly.What’s

    more,unique standardized and module production ensure our products continuous quality.



    Competitive Price

    With large scale production capacity and professional production technology,our company have built

    effective modular production.We always stick to promote the technical innovation and reduce cost to

    benefit customers.



    Fast Delivery

    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

    inventory will be used to maintain your uninterrupted supply of the products.



    Perfect Service

    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

    you.

    After-sales:We will track the products usage and then constantly perfect our products.
