IP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years Warranty

IP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years Warranty

    • IP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years Warranty
    • IP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years Warranty
    • IP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years Warranty
  • IP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years Warranty

    Product Details:

    Place of Origin: Made in china
    Brand Name: SCXK
    Certification: CE,ROHS, FCC.UL.CUL
    Model Number: SCXK-p6

    Payment & Shipping Terms:

    Minimum Order Quantity: one cabinet sand one module can be avaiable.
    Price: Negotiable
    Packaging Details: wooden box, flight case, paper box can be available( All kinds of the box will guarantee the safety of the led display
    Delivery Time: within 7-10days, the led disdplay can be sent to you after your payment
    Payment Terms: D/A, L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Contact Now
    Detailed Product Description
    Material: Iron And Steel Cabinet Cabinet Size: 960mm X960mm
    Warranty: 3 Years Led Chip: Epistar
    Life Span: 100000hours Power Supply: AC100V~240V
    Pixels: 6mm

    Top rated item Shopping Mall Stadium outdoor Full Color LED video wall screen
    Specification as follows



    LED Lamps Type SMD2727(High Brightness LEDs)
    LED Standard Real Pixel(1R1G1B)
    Red Wavelength 625-630nm
    Green Wavelength 515-530nm
    Blue Wavelength 465-475nm
    LED Module Pixel Pitch 6mm
    Module Size 320mm x160mm
    Module Resolution 64*32dots
    LED Cabinet Cabinet Size 960mmx960mm
    Cabinet Resolution 128dotsx128dots
    Cabinets Material iron and steel cabinet
    LED Display Pixel Density 62500pixels/sq.m
    Drive IC MBI5024
    Power Supply Series connection
    Brightness >2000cd/sqm
    Display Color 16.7million
    Viewing Angle 160°(Horizontal),110°(Vertical)
    Best Viewing Distance 6m~200m
    Max Power Consumption 1000 w/sq.m
    Average Power Consumption     300 w/sq.m
    Weight 22kgs/sq.m
    Refresh Rate 2500hz
    Input Voltage AC220V/50H or AC110V/60H
    Output Voltage DC5V,40A
    Grey Scale Levels 16bit
    Display Colors R(1024) x G(1024) x B(1024)
    MTBF 10,000 hours
    Life-span 100,000 hours
    Protection Level IP65
    Failure percentage of leds     less than 0.0003
    Working Temperature -25℃-60℃
    Drive Mode 1/32 scaning
    Working Humidity 10%~99%
    Control System Control method Synchronization & Asynchronization
    Control System (software) Led studio
    Software LED studio
    Input Signal MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc
    PC Operating system Microsoft Windows 7, 98, 2000, XP and Vista


    Competitive advantage


     IP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years Warranty



    Led moduel we have

                                             Indoor outdoor full color SMD 3 in 1 led display
    P2 Iron cabinet 1/32scan 256x128 128x64dots 250000dots 512x512 $1,905.50 wooden packaged
    P2 die cast aluminum 1/32scan 256x128 128x64dots 250000dots 512x512 $2,301.50 flight case package
    P2.5 Iron cabinet 1/16scan 160x160 64x64dots 160000dots 640x640 $1,111.50 wooden packaged
    P2.5 die cast aluminum cabinet 1/16scan 160x160 64x64dots 160000dots 480x480 $1,195.50 flight case package
    P3 Iron cabinet 1/32scan 192x192 64x64dots 111111dots 576x576 $795.50 wooden packaged
    P3 die cast aluminum cabinet 1/32scan 192x192 64x64dots 111111dots 576x576 $842.50 flight case package
    P3.91 Die cast aluminum (smd) 1/16scan 250X250 64x64dots 65410 dots 500X500 $795.50 flight case package
    P4 iron cabinet(smd) 1/16scan 256X128 64x32dots 62500dots 768x768 $603.50 wooden packaged
    P4 die cast aluminum cabinet (smd) 1/16scan 256x128 64X32dost 62500dots 512x512 $655.50 flight case package
    P5 Iron cabinet 1/16scan 320x160 64x32dots 40000dots 640x640 $480.50 wooden packaged
    P5 die cast aluminum cabinet 1/16scan 320X160 64X32dots 40000dots 640x640 $555.50 flight case package
    P6 iron cabinet 1/16scan 384x192 64X32dost 27777 dots 768x768 $398.50 wooden packaged
    P6 die cast aluminum cabinet 1/16scan 192X192 32x32dots 27777dots 576x576 $478.50 flight case package
    p10 iron cabinet 1/8scan 320x160 32x16dots 10000dots 960x960 $350.50 wooden packaged
    All the pricelist include the control system,3 years warranty!(we will send some spare parts based on your order



    For post-sale service. We can instruct you how to use, adjust the screens, and change the boken modules with spare parts. For asynchronous control We use Onbon, or Xixun control system.



    Applications:



    Airport Full Color Indoor LED displays

    Train station Indoor Full Color LED Displays

    Entertainment Bar Indoor Full Color LED Screen

    Stadium Indoor Full Color LED Display

    Museum Full Color Indoor LED display

    Car exhibition LED display

    Conference room Indoor Full Color LED Video Display

    Shopping Mall Indoor Full Color LED display

    IP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years WarrantyIP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years WarrantyIP65 Full Color LED Video Wall Screen Iron / Steel Cabinet 3 Years Warranty
    FAQ



    Q1. What's the warranty of your LED Display Screen ?

    A1. We have a 3-years warranty for our led display screen, and 100,000 hours life span of the led lamps.


    Q2. What about your pre-sale service and post-sale service?

    A2. For pre-sale service. We have a professional sales team and a 8 years technical team who are willing to answer your question 24/7.

    We can offer a whole complete solution for your project!

    For post-sale service. We can instruct you how to use, adjust the screens, and change the boken modules with spare parts.

    Also, we can send technicals to your country to solve problems. Mostly, our led display will not have big problems within warranty time!
