Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | CHINA |
| Brand Name: | SCXK |
| Certification: | CE,ROHS,FCC,SASO |
| Model Number: | SCXK-P3.91/P4.81 |
| Minimum Order Quantity: | 10 SQM |
|---|---|
| Price: | USD 600-2000 |
| Packaging Details: | wooden case, flight case |
| Delivery Time: | 7-10 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000 sqm month |
| Application:: | Commerce | Color:: | Full Color |
|---|---|---|---|
| Panel Size:: | 250*250mm | Pixel Pitch:: | 3.91mm |
| Screen Dimension:: | Customized | Module Size:: | 250m*250m |
| LED Chip:: | Kinglight | Viewing Angle:: | 160/160 |
| Pixel Configuration:: | SMD 3in1 | Lifespan:: | 75000-100000hours |
| Control System:: | Novastar | Working Temperature:: | 22 ~122 (-20 ~ 50 ) |
| Brightness:: | 1200cd/sqm | ||
| High Light: | P3.91 Stage Rental Led Panel,1200nits Stage Rental Led Panel,280W Dj Background LED Screens |
||
Indoor ultra-thin HD advertisingP3.91/P4.81 mall full color LED display widescreen large viewing angle
♦ Features:
1. Ultra-high resolution and wide viewing angel.
2. Fixing and rental use creates more applications.
3. High refresh rate 1920Hz, best scan method for energy saving, perfect grey level.
4. Wireless: seamless installation simplifies the complex inner structure, improving its safety and stability.
5. Thin: it is featured by high strength, toughness, precision and it is hard to be deformed.
6. Easy: the die-casting aluminum cabinet is modular designed, each cabinet of the screen can be easily dismantled and assembled(replaced).
7. Low: low noise, light weight, low cost for transportation and assembling without tools with low cost for assembling.
8. Economical: Design of low power consumption, no need cooling fan, meet the demand of quiet work environment.
9. Perfect uniformity and no mosaic.
♦ Product specification
| indoor SMD P3.9 | |||||||||
| Lamp size | 3.9 | ||||||||
| Resolution/mm | 3.9 | ||||||||
| Pixel configuration | RGB 3 in 1 | ||||||||
| Pixel density/pixels/m² | 65410/m² | ||||||||
| Module resolution | 64x64 | ||||||||
| Module size/mm | 250x250 | ||||||||
| View distance | ≥3m | ||||||||
| Single point brightness adjust | Can be added | ||||||||
| Single point color adjust | Can be added | ||||||||
| White balance brightness | >2500cd/㎡ | ||||||||
| Color temperature | 6500K-9500K | ||||||||
| Horizontal view angle | 120(degrees) | ||||||||
| Vertical view angle | 60(degrees) | ||||||||
| Signal Process bit | 10 or 14 bit | ||||||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:5km | ||||||||
| Driving mode | Constant driving current | ||||||||
| Scanning mode | 1/16 | ||||||||
| Frame rate | 60Hz | ||||||||
| Refresh frequency | >3000Hz | ||||||||
| Control mode | Computer synchronous | ||||||||
| Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
||||||||
| Out of control point | <1/10000 | ||||||||
| Working hours | ≥72hours | ||||||||
| Mean Time Between Failure | >5000hours | ||||||||
| Life time | 100000hours | ||||||||
| Life-all-white(brightness halving) | 50000hours | ||||||||
| Environment temperature range | Operating temperature range: -20-45℃ Storing temperature range: -30-65℃ | ||||||||
| Maximum power:/㎡ | <1100W | ||||||||
| Average power:/㎡ | <280W | ||||||||
| Self-check technology |
LED spot self-check, communications check, power check, temperature monitor(need customization) |
||||||||
| Remote monitoring |
Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
||||||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||||||
| Luminous point width between centres | Deviation<3% | ||||||||
| Brightness uniformity | <10% | ||||||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||||||
| Contrast | (1000:1) | ||||||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||||||
| Humidity(working) | working:10-95% | ||||||||
| Humidity(storing) | storing:10-95% | ||||||||
| Product overviews | |
| Items | Indoor Led display: P1.5 P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10 Outdoor Led display: P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25 Dance floor led display |
| Material | steel,aluminum ,die casting aluminum |
| Certificates | CE, FCC,RoHS, CCC, UL |
| Payment terms |
30% deposit before production, 70% balance before shipping |
| T/T | |
| Western Union | |
| Packing: | Standard Export Carton with fully Polyfoam or Pearl Wool |
| Flight case; | |
| Anti-shaking wooden case | |
| Shipping: | 5 to 7 working days upon receiving deposit payment |
| After-Sales-Service: | Lifetime with professional engineer support for free. |
| Within 5 year, supply spare parts for free if has quality problem ( not by man-made damage) |
|
| Using Range | Shopping mall,bank,bus station, train station, center of downtown, airport, school, factory, bus, taxi,and so on. |
