High quality and resolution indoor full color led led display 3 years warranty P5 smd3528

High quality and resolution indoor full color led led display 3 years warranty P5 smd3528

  • High quality and resolution indoor full color led led display 3 years warranty P5 smd3528
  • High quality and resolution indoor full color led led display 3 years warranty P5 smd3528
High quality and resolution indoor full color led led display 3 years warranty P5 smd3528
Product Details:
Place of Origin: made in china
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: SCXK-P5
Payment & Shipping Terms:
Minimum Order Quantity: 5sqm
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Material: Steel And Aluminum Color: RGB
View Distance: 5m-200m Module Size: 320mm X160mm
Chip: Kinglight/Nationstar Warranty,: 3 Years
Usage: Indoor Life Span: 100000 Hours
High Light:

led full color screen

,

indoor led display screen

High quality and resolution indoor full color led led display 3 years warranty P5 smd3528



We have more than 12years design experience of offering solution, installation, and after-sales service, etc. According to different environment conditions, too cold temperature till -40℃ or too hot temperature till +55℃, we carefully choose different suitable materials and make the best offer for every customer. It differs in cables, LED lamps, plastic masks, waterproof materials, IC, etc. Faced with a variery of requirements, we offer flexible diverse solutions. We offer 24-hour all- direction online service.



P5 SMD Indoor Full Color LED Display Screen


5mm pixel pitch,1R1G1B,27777dots/sqm,P5 SMD Outdoor Full Color LED Display Screen creates high brightness and energy saving,

display variable video resources,animations,messages to attract attention. We can see p5 SMD Outdoor Full Color LED Display Screen in many occasions,like Sports,advertising,traffic,entertainment,stage,events,stations,shopping center,airport,exhibitions, car shows, fashion shows, concerts, ceremonies, etc





Application Areas

·---Outdoor advertising, digital billboards, advertising in big companies

·---Sports halls, fields, playgrounds.

·---Airports, bus stations and railway passenger terminals.

·---Facades of shopping malls, department stores, banks and car dealerships.

·---Architecture and social projects, information systems in cities.

·---Show-business, concerts, festivals, motor shows and other public events.


High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 0



    Specifictions
LED Lamps Type SMD3528(High Brightness LEDs)
LED Standard Real Pixel(1R1G1B)
Red Wavelength 625-630nm
Green Wavelength 515-530nm
Blue Wavelength 465-475nm
LED Module Pixel Pitch 5mm
Module Size 320mx160m
Module Resolution 64*32dots
LED Cabinet Cabinet Size 960mmX960mm
Cabinet Resolution 192pixels *192pixels
Cabinets Material Iron steel cabinet
LED Display Pixel Density 62500pixels/sq.m
Drive IC MBI5024
Power Supply Series connection
Brightness >15000cd/sqm
Display Color 16.7million
Viewing Angle 110°(Horizontal),50°(Vertical)
Best Viewing Distance 5m~200m
Max Power Consumption 600 w/sq.m
Average Power Consumption 300 w/sq.m
Weight 35Kgs/sq.m
Refresh Rate 3000hz
Input Voltage AC220V/50H or AC110V/60H
Output Voltage DC5V,40A
Grey Scale Levels 16bit
Display Colors R(1024) x G(1024) x B(1024)
MTBF 10,000 hours
Life-span 100,000 hours
Protection Level IP43
Failure percentage of leds less than 0.0003
Working Temperature -25℃~65℃
Drive Mode 1/16 scaning
Working Humidity 10%~99%
Control System Control method Synchronization & Asynchronization
Control System LINSN Control System (sender,receiver,HUB with 75 interface,software)
Software LED Studio (LINSN)
Input Signal MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc
PC Operating system Microsoft Windows 7, 98, 2000, XP and Vista



High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 1High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 2High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 3High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 4



Quick Detail:
1) Stable quality:Opto + Silan chipset;
2) High brightness:>8500 nits;
3) Scan driver:1/4 current;
4) Module size(L*W):192*192mm;





Competitive Advantages:
1) Stable quality and fast Response;
2) Short delivery,effective production;
3) Sample order,trial order be acceptable;
4) Good communication;
5) 3 years warranty;





High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 5









♦ Why choose us:



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.

High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 6

High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 7High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 8



♦ Applications



--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.



♦ FAQ



What kind of payment terms you can accept ?



We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.



High quality and resolution indoor full color led led display 3 years warranty P5 smd3528 9
