Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | ShenZhen in China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P6 |
| Minimum Order Quantity: | 2sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | Western Union, MoneyGram, D/P, T/T, L/C |
| Supply Ability: | 5000sqm per month |
| Pixels: | 6mm | Tube Chip Color: | Full Color |
|---|---|---|---|
| Led Type: | SMD3528 | Display Function: | Video |
| Cabinet: | Die-casting Aluminum | Cabinet Size: | 192mm*192mm |
| Working Voltage: | DC5V | Warranty Time: | 3 Years |
| Dot Density: | 27778 | Driving Mode: | 1/8scaning |
| Certificates: | CE,RoHs,FCC,ISO | Piexl Dots: | 32*32 |
| Screen Size: | 576*576mm | ||
| High Light: | led display smd,outdoor smd led display |
||
Die Casting Aluminum Indoor Rental LED Display Screen super thin high gray grad
1, stage led display screen
2,High refreashing rate can be 3840-4000hz, good color balance
3,Our company specailly design ,fastly to connecting each cabinet and slim light cabnet
4,Big View angle 150Degrade
5,Best mask consistance,
6,Lift time service always, No worry on afterservice
Specifications:
1.High brightness and high refresh rate, highly durable
2.Die casting Aluminum cabinets
3.Super Slim &Light Weight
4.Easy to maintain and fast installation
5.Low power consumption and long lifespan
Technical parameters
| Module | Item | Parameter |
| Model Number | P6 | |
| Module size | 192mm*192mm | |
| Pixel pitch | 6mm | |
| Pixels Density | 27778dots/sqm | |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD3528 | |
| Pixel resolution | 32dots(W)*32dots(H) | |
| Max Power | 22W | |
| Module thickness | 17.05mm | |
| Weight | 0.15kg | |
| Drive type | Constant drive | |
| Scan mode | 1/8can | |
| Port type | HUB75 | |
| Brightness of white balance | ≥5000cd/sqm |
| Cabinet | Module Quality | 9 |
| Power supply | 5V/60A*1pcs | |
| Thermal discharge | fan 1pcs | |
| Pixel per cabinet | 192*192 | |
| Best viewing distance | 4M~200M | |
| Best viewing angle | 160°(W) 120°(H) | |
| Temperature | storage:-35℃~+85℃ | |
| working:-20℃~+50℃ | ||
| Relative humidity | 10%-95% | |
| Thickness | 85mm | |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | 195W/sqm | |
| Max.Power consumption | ≤487W/sqm | |
| Current | ≤20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
| Main technical | Driving device | Constant drive IC |
| Refresh frequency | ≥3600HZ | |
| Grey scale/colors | 4096 16.7M | |
| 4096gray level/16.7M colors | ||
| MTBF | ≥9000hours | |
| Power switch | Automatic switch | |
| Display Mode | ≥800*600/1024*768 |
Advantages of our P6 rental led display?
1.High quality:
1) Our most attention is the product quality.
2) Our most basic guarantee: the aging time exceeding 24 hours. Malfunction dot rate
less than 0.0001. MTBF more than 10000 hours.we assure high brightness and long
lifespan.
2.Attractive Factory Price:
We are professional manufacturer, has its own factories and production lines. Without
middlemen and trading companies, our price is more competitive, quality is more reliable.
3.Perfect Display Effect:
High brightness and clearly led display effect with easy use control system which allow you
easy become enviable led display experts.
4.Auto equipment:
Kailite has several auto production lines equipment with Taiwan auto-encapsulate machine,
Taiwan ChangYu handler, and the production of LED meets the demand of high quality standard
LED display.
5. After-sales service :
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution
supplied in 48 hours.
Why Choose us?
Packing&shipping
Packing: wooden case, flight case for choose
shipping: by air, sea, train, DHL, you are the boss
