Home ProductsHanging LED Display

P10 P8 P6.67 P6 Big Outdoor Advertising Led Display High Brightness For Event / Stage / Show

P10 P8 P6.67 P6 Big Outdoor Advertising Led Display High Brightness For Event / Stage / Show

    • P10 P8 P6.67 P6 Big Outdoor Advertising Led Display High Brightness For Event / Stage / Show
    • P10 P8 P6.67 P6 Big Outdoor Advertising Led Display High Brightness For Event / Stage / Show
  • P10 P8 P6.67 P6 Big Outdoor Advertising Led Display High Brightness For Event / Stage / Show

    Product Details:

    Place of Origin: ShenZhen in China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P6

    Payment & Shipping Terms:

    Minimum Order Quantity: 2sqm
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: Western Union, MoneyGram, D/P, T/T, L/C
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Pixels: 6mm Tube Chip Color: Full Color
    Led Type: SMD3535 Display Function: Video
    Cabinet: Die-casting Aluminum Iron ,it Is Up You Cabinet Size: 192mm*192mm
    Working Voltage: DC5V Warranty Time: 3 Years
    Dot Density: 27778 Driving Mode: 1/8scaning
    Certificates: CE,RoHs,FCC,ISO Piexl Dots: 32*32
    Screen Size: 960*768mm/576*576mm



    P10 P8 P6.67 P6 Big Outdoor Advertising Led Display High Brightness For Event / Stage / Show




    [ Characteristic of Rental LED Display Screen ]

    Famous Brands Raw Material Selection



    1)LED: well-known international brand, with wide viewing angle, high brightness, little attenuation, good heat dissipation, and vivid colors.



    2) Driving IC: famous brands such as, Taiwan MBI, Japanese Toshiba, avoidable the defective phenomena, such as dark bright, virtual light and so on.



    3) Power supply: industrial-strength brand. The power t maximum power reserve of 20% the space, the range of voltage fluctuation is less 5%, high stability.



    4) Connector: Aerial grade brands ensure the stable transmission of power and signal.



    5) PCB Board: adopt 4-layer design.



    6) Easy installation:100 pieces of cabinets' installation can be finished in one hour by one person. The replacement of any cabinet can be done within 50 seconds.



    Product Description



    No. Item P6 P6.67 P8 P10
    0 Price $3115/sqm $2230/sqm $1885/sqm $1148
    1 Pixel Pitch 6mm 6.67mm 8mm 10mm
    2 Pixel Configuration SMD DIP146 DIP146 DIP346
    3 Pixel Density 27777pixels/sqm 22478pixels/sqm 15625pixels/sqm 10000pixels/sqm
    4 Module size 240mm*240mm 320mm*160mm 320mm*160mm 320mm*160mm
    5 Module Resolution 40*40pixels 48*24pixels 40*20pixels 32*16pixels
    6 Cabinet size 480mm*480mm 640mm*640mm 640mm*640mm 640mm*640mm
    7 Cabinet Resolution 80*80Pixels 96*96Pixels 80*80Pixels 64*64Pixels
    8 Cabinet Thickness 5cm 6.5cm 6.5cm 6.5cm
    9 Weight 8Kgs 18Kgs 18Kgs 18Kgs
    10 Brightness >6000cd/sqm >7000cd/sqm >7000cd/sqm >7000cd/sqm
    11 Refresh rate >1500HZ >1500HZ >1500HZ >1500HZ
    12 Gray scale 65536,1.07billion colors 65536,1.07billion colors 65536,1.07billion colors 65536,1.07billion colors
    13

    View angle

    (H/V)

    ≥120°/6 ≥120°/6 ≥120°/6 ≥120°/6
    14

    Max Power

    consumption

    300W/Cabinet 400W/Cabinet 400W/Cabinet 400W/Cabinet
    15

    Average Power

    consumption

    150W/Cabinet 200W/Cabinet 200W/Cabinet 200W/Cabinet
    16 Input Voltage AC110/220V±15%,50-60Hz
    17 Working temperature -20~-45 -20~-45 -20~-45 -20~-45
    18 Working Humidity 10%-90%RH 10%-90%RH 10%-90%RH 10%-90%RH
    19 IP Grade IP65/IP54 IP65/IP54 IP65/IP54 IP65/IP54



    P10 P8 P6.67 P6 high Brithness aluminum die case outdoor full color led display event stage show hanging big screen

    Specifications:



    1.High brightness and high refresh rate, highly durable



    2.Die casting Aluminum cabinets
    3.Super Slim &Light Weight
    4.Easy to maintain and fast installation
    5.Low power consumption and long lifespan



    what is the advantages of our P6 outdoor led screen?

    1.High quality:
    Our most attention is the product quality.

    Our most basic guarantee: the aging time exceeding 24 hours. Malfunction dot rate less than 0.0001. MTBF more than 10000 hours.we assure high brightness and long lifespan.

    2.Attractive Factory Price:

    We are professional manufacturer, has its own factories and production lines. Without middlemen and trading companies, our price is more competitive, quality is more reliable.

    3.Perfect Display Effect:

    High brightness and clearly led display effect with easy use control system which allow you easy become enviable led display experts.

    4.Auto equipment:

    Kailite has several auto production lines equipment with Taiwan auto-encapsulate machine, Taiwan ChangYu handler, and the production of LED meets the demand of high quality standard LED display.

    5. After-sales service :

    1. Lifetime free maintenance and upgrade.

    2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.



    Our Service



    1) Guidance service: We can guide on line if customers have questions about the installation and usage.

    For large project, we provide your engineer a week free training, or if customer could bear the relevant cost,

    our engineer can go to customer’s country for on-site guidance.



    2) Warranty period: 2 years after shipment.



    3) Maintenance principles: response in time, solve problems as soon as possible and ensure the use.



    4) Maintenance terms: In the Maintenance period, free of all maintenance charges.

    Under normal use and storage, our company will be responsible for the equipments.



    If there is any failure in product quality, our company will maintain and change the components for free.

    After Maintenance period, only charge the material costs fees free of manual work fees.



    Company Information

    SCXK has been specialized in LED field since 2005. We are a leading manufacturer an provider of technical solution of full color indoor an outdoor ledisplay,rental LED display, led modules where in Shenzhen ctiy,Guangdong province,China.
