Professional Outdoor digital SMD LED Screen comercial advertising 3 years warranty

Professional Outdoor digital SMD LED Screen comercial advertising 3 years warranty

    • Professional Outdoor digital SMD LED Screen comercial advertising 3 years warranty
    • Professional Outdoor digital SMD LED Screen comercial advertising 3 years warranty
  • Professional Outdoor digital SMD LED Screen comercial advertising 3 years warranty

    Product Details:

    Place of Origin: ShenZhen in China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P8

    Payment & Shipping Terms:

    Minimum Order Quantity: No limit
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: Western Union, MoneyGram, D/P, T/T, L/C
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Pixels: 8mm Tube Chip Color: Full Color
    Led Type: SMD3535 Display Function: Video
    Cabinet: Steel Or Aluminum For Options Cabinet Size: 512mm*512mm
    Working Voltage: DC5V Warranty Time: 3years
    Dot Density: 15625 Driving Mode: 1/4 Scaning
    Certificates: CE,RoHs,FCC,ISO





    Professional Outdoor digital SMD LED Screen comercial advertising 3 years warranty


    Product Features
    • Advanced video processing produces crystal-clear, detailed images with smooth motion reproductions.
    • High brightness assures images clear and vivid under glaring sunlight; low attenuation, and all weather defense.
    • Full-depth color and brightness calibration in the factory and in the field provides for a uniform display picture.
    • Excellent cooling effect, operating without any noise.
    • Lightweight, thin design, low transportation cost and installation cost.

    Module Parameter:

    Pixel pitch8mm
    Pixel Density15,625 dots/m²
    Pixel configuration1R1G1B
    LED type3-in-1 SMD3535
    Module size256*128mm
    Module weight330g
    Module resolution32*16dots
    Module quantity30.52 pcs/m²
    Min. Viewing Distance ≥8m
    Brightness≥5500 cd/m²
    Viewing AngleH≤120° V≤120°
    Driving Mode1/4 scan constant current driving
    InterfaceHUB75
    Input voltage4.8-5.5VDC
    Max. Power Consumption850 w/m²
    Avg. Power Consumption400 w/m²
    Max. Current3.6-4.0A
    Frame rate60 frames/s
    Refresh Rate≥600Hz
    Defective Dots Rate<0.0001 (LED display line standard: ≤ 0.0003)
    Decay Rate≤5%/year
    Brightness Conformity >95%
    MTBF≥10000 hours
    Lifespan≥50000 hours
    Protective function

    Over-heat/Over-load /Power-down /Power-leakage/Lightning
    -protection etc.

    Operating Temperature -20℃~+50℃
    Operating Humidity10-85% no condensation
    Storage Temperature-30℃~+60℃
    Storage Humidity10-95% no condensation


    1.Clear picture without flicker and distortion
    2. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive
    3. Low consumption, stable performance, highly durable
    4. High brightness & broad viewing angle, brightness can be adjusted automatically or manually
    5. 2 years warranty, easy to install & maintenance
    p8 outdoor led display module :
    Professional Outdoor digital SMD LED Screen comercial advertising 3 years warranty
    Our service:

    1.Your inquiry related to our products or prices will be replied in 24hrs.
    2.Well-trained and experienced staffs to answer all your enquires in fluent English .
    3.OEM&ODM, any your customized screen we can help you to design and put into product.
    4.Distributoer ship are offered for your unique design and some our current models .
    5.Protection of your sales area, ideas of design and all your private information

    Trade terms:
    1. Hardware: LED display and video controlling system
    2. Technical material: English version user manual, installation manual And maintenance manual
    3. Service:Provide free technology support by phone and e-mail 7 years guarantee
    4. Delivery: Approx 3-12 working days
    5. Packing: Anti-shaking wooden package or Air Flight Case.
    6. Transportation: By sea or air or Express

    Hope we can work together!
