Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | ShenZhen in China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/CB |
| Model Number: | P3 |
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Pixels: | 3mm | Tube Chip Color: | Full Color |
|---|---|---|---|
| Cabinet: | Steel Or Aluminum For Options | Pixel Configuration: | 1R1G1B |
| Warranty: | 3 Years | Brand: | SCXK |
| Module Size: | 192*192mm | ||
| High Light: | led full color screen,indoor led billboard |
||
♦ Description:
This kind of product is special for indoor or outdoor column facade, can be cylinder and square shape. 360 degree viewing angle show a perfect viewing experience.
Front service makes it easy to maintain if there is any problem. City development and improvement need this kind screen better.
Especially square LED screen, we can support any pixel pitch according to your project requirement, group control makes it easily.
♦ Product specification
| indoor SMD P3 | ||||||||||||||
| Lamp size | 2121 | |||||||||||||
| Resolution/mm | 3 | |||||||||||||
| Pixel configuration | RGB 3 in 1 | |||||||||||||
| Pixel density/pixels/m² | 111111/m² | |||||||||||||
| Module resolution | 64x64 | |||||||||||||
| Module size/mm | 192x192mm | |||||||||||||
| View distance | ≥3m | |||||||||||||
| Single point brightness adjust | Can be added | |||||||||||||
| Single point color adjust | Can be added | |||||||||||||
| White balance brightness | >2000cd/㎡ | |||||||||||||
| Color temperature | 6500K-9500K | |||||||||||||
| Horizontal view angle | 120(degrees) | |||||||||||||
| Vertical view angle | 60(degrees) | |||||||||||||
| Signal Process bit | 10 or 14 bit | |||||||||||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | |||||||||||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:5km | |||||||||||||
| Driving mode | Constant driving current | |||||||||||||
| Scanning mode | 1/8 | |||||||||||||
| Frame rate | 60Hz | |||||||||||||
| Refresh frequency | >3000Hz | |||||||||||||
| Control mode | Computer synchronous | |||||||||||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
|||||||||||||
| Out of control point | <1/10000 | |||||||||||||
| Working hours | ≥72hours | |||||||||||||
| Mean Time Between Failure | >5000hours | |||||||||||||
| Life time | 100000hours | |||||||||||||
| Life-all-white(brightness halving) | 50000hours | |||||||||||||
| Environment temperature range | Operating temperature range: -20-45℃ Storing temperature range: -30-65℃ | |||||||||||||
| Maximum power:/㎡ | <900W | |||||||||||||
| Average power:/㎡ | <300W | |||||||||||||
| Self-check technology | LED spot self-check, communications check, power check, temperature monitor(need customization) |
|||||||||||||
| Remote monitoring | Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
|||||||||||||
| Software environment | WindowsNT,Windows1999,WindowsXP | |||||||||||||
| Luminous point width between centres | Deviation<3% | |||||||||||||
| Brightness uniformity | <10% | |||||||||||||
| Color uniformity(chromaticity coordinate) | ±0.003 | |||||||||||||
| Power supply request | AC85-264V(50Hz-60Hz) | |||||||||||||
| Contrast | (1000:1) | |||||||||||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | |||||||||||||
| Humidity(working) | working:10-95% | |||||||||||||
| Humidity(storing) | storing:10-95% | |||||||||||||
♦Advantage:
1. Natural Heat Dissipation (no cooling system needed)
2. Stunning Visual Experience
3. High recall rate and attracting customers
(1) High brightness DIP LED is used for outdoor led display, keeps the display content visible even if facing the strong sunshine directly.
(2) With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.
(3) Weatherproof design, completely outdoor use.
(4) Easy for assembling and connection with the connector added.
(5) High color uniformity and clear image can bring you a vivid audio visual effect.
(6) Both front and rear access are available.
(7) The LED Chips that we use have the advantages of large viewing angle, low power consumption and good color uniformity.
(8) Use the same level of red, green and blue led chips, which makes the image display of whole led display more excellent and uniform.
(9) The maintenance of pixel and single led has been realized.
(10) Good quality raw material, accurate technique and careful inspection insures the high quality of led display
Application:Ministry of Transport, police office, army office, energy department,meteorological department, water conservancy office
Quality
100% brand new
Payment
Bank transfer or Western Union, L/C, and etc.
Packing and delivery
Within 30 working days after confirming payment.
Packed in anti-static bags,bubble bags,foam box and carton to ensure safety in transportation, or customized single box.
Shipping
by airway, Freight, or depends on your requirement, the packing photos and the tracking number will be updated after delivery.
After-sale service
Please feel free to contact us for any problem any time, we will help you solve.
Can i get a sample?
Yes, if we have storage, we will ship to you the same day.
If not, normally we need 5 working days for the sample.
And you can get promotion for less than MOQ one chance.
Do you have MOQ?
It is 5 piece normally.
How do you ship the goods?
As for express way, we adopt DHL mainly, we calculate as follows:
Less than 21kg, 6.5usd/initial 0.5kg+6.5usd for next each 0.5kg
More than 21kg, 6.5usd/kg
30usd per shipment will be required for remote address
What is the payment method
Alibaba trade assurance, Paypal, WesternUnion, and
T/T method, 25% deposit and the rest shall be paid out before shipment
Can i print my LOGO?
Yes, and we can also provide the package with your logo for mass production, it is FREE
What is the guarantee
We guarantee all our items 3 years
