Hd Full Color P4.81 Rental LED Display 3D Video , Indoor Outdoor Led Screen Hire

Hd Full Color P4.81 Rental LED Display 3D Video , Indoor Outdoor Led Screen Hire

  • Hd Full Color P4.81 Rental LED Display 3D Video , Indoor Outdoor Led Screen Hire
  • Hd Full Color P4.81 Rental LED Display 3D Video , Indoor Outdoor Led Screen Hire
Hd Full Color P4.81 Rental LED Display 3D Video , Indoor Outdoor Led Screen Hire
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P4.81
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T or western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: P4.81 Rental Led Display Module Size(W * H): 250mm*250mm
Standard: CE/ROHS/FCC/ISO2001 Tube Chip Color: Full Color
Pixel Pitch: 4.81mm Module Qty: 1pcs
Type: Free Standing Resolution(W*H): 52dots*52dots
High Light:

rental led display screen

,

led rental screen

indoor full color p4.81 rental hd video super clear hd led screen,rental led display

About our factory:



Shenzhen Shichuangxinke Electronic Co.,Ltd was founded in 2005, is headquartered in Shenzhen, China.

we have been exported to USA,Canada,Argentina,Brazil,Ecuador,Venezuela,Honduras,Germany,Spain,Moldova,Poland,Netherlands,Russia,Sweden,France,Belgium,Turkey,Israel,Saudi Arabia,South Africa,Uganda,Egypt,Angola,India,Vietnam,Thailand,New Zealand,Australia and other 50 countries and regions,and gained a great reputation from customers.



We are the responsible manufacture who focus on LED display and LED lighting manufacturing and engineering solutions. SCXK has its own serial of advanced machines such as Full Automatic SMT Machine, Peak Welding Machine and Reflow Welding Machine for production. We make every processing of LED module which is most important part of LED display, which makes us a strict control of production procedures and product quality. Not only we focus on the R&D of products, but also we emphasize the quality. We are a production enterprise; we solve all the worries about quality for our customers. During production, we have strict Quality control, making sure every LED display have gone through strict tests and aging before enter into market.


We will do better and we will achieve higher.SCXK LED will strongly promote the channel construction, the channel objectives are: to provide one-stop service to any demand customers.



Our Service



1)Training after order

After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment



2) Installation and debugging

BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.



3) Warranty

Warranty: 2 years warranty, lifetime maintenance

Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.



4) Maintenance

Maintenance principles: response in time, solve problems asap and ensure the use.

Maintenance period: In the maintenance period of the led display body, free of all maintenance charges

After maintenance period, only charge the material cost and labor cost.



Specifications



 p4.81 led module
LED Module Display
Type SMD 3in1 Max.power consumption Max 1200W/sq.m
Pixel configuration 1R1G1B Avg.power consumption Max 600W/sq.m
Drive mode 1/13 scanning Max.current. Max 5.02A/220V, 50HZ
Module Re.(Dot) 52*52(W*H) H/V viewing angle 120/120
Pixel pitch(mm) 4.81mm Brightness(CD) Min 1300cd
Module size(mm) 250mm*250mm(W*H) Pixel density(Dot) 111111
Cabinet Power factor Min 0.7
LED board array 52*52(W*H) Cert. UL,CE,ETL,ROHS
Cabinet Re.(Dot) 104*104(W*H) Contrast 2000:01:00
Cabinet area 0.25 sq.m Working temperature -10--50
Cabinet size 500*500mm(W*H) Working humidity 20% to 90%
Weight 18kg Alumimum/Cild rolled sheet Lifespan(50%) 100,000hours
Power AC220/110,47~63HZ Processing 10 bit
Frame rate 60 fps Colors 687 billion
Dimming level Manual-100 levels, Automatic-16 levels Refresh frequency Min 800Hz





♦ Production process:



→1) Incoming Inspection→2)SMD→3)Plug-in

→4) Wave Soldering→5)After Welding→6)Testing

→7) Semi Finished Aging→8)Module Assembly

→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing



♦ Product specification



1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.



Hd Full Color P4.81 Rental LED Display 3D Video , Indoor Outdoor Led Screen Hire 0



♦ Packaging and shipping




Wooden case or flight case package are available.

Shipping by sea,air or DHL,multiple shipping ways for your choice.



A. Flight case Packing
1)150KG Per flight case
2)3 cabinets in one case
3)Flight case size: 1010mm*560mm*1175mm=39inch*22inch*46inch



B. Plywood case
1)180KG per plywood case
2)3 cabinets in one case
3)Plywood case size: 1120mm*585mm*930mm= 44inch*23inch*36inch



C.customized packing is acceptable
D. 20"FT container loading of 100sq.m




♦ Why choose us:



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-10 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.
