RGB SMD 3528 Digital Led Mobile Advertising Trucks Environment Friendly

RGB SMD 3528 Digital Led Mobile Advertising Trucks Environment Friendly

    • RGB SMD 3528 Digital Led Mobile Advertising Trucks Environment Friendly
    • RGB SMD 3528 Digital Led Mobile Advertising Trucks Environment Friendly
  • RGB SMD 3528 Digital Led Mobile Advertising Trucks Environment Friendly

    Product Details:

    Place of Origin: ShenZhen in China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: P10

    Payment & Shipping Terms:

    Minimum Order Quantity: 2 sqm
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: Western Union, MoneyGram, D/P, T/T, L/C
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Pixels: 10mm Tube Chip Color: Full Color
    Led Type: SMD 3528 Display Function: Video
    Waterproof: Ip65 Cabinet: Steel Or Aluminum For Options
    Frame Frequency: >=60HZ Average NO Failure: >=1000hours
    Transmiiting Distance: Internet Cable <100m Refresh Rate: >=180HZ
    Maximum Power: 600m2 The Optimum: 600w/m2
    Module: 320*160mm Cabinet Size: 960*960mm





    RGB SMD 3528 Digital Led Mobile Advertising Trucks Environment Friendly





    Product Description

    Features of Product:

    1) High intensity and can be adjusted, so can meet the request of the customers according the application environment;
    2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light;
    3)To pictures and character, have clear, exquisite and real display effect;
    4) Big viewing angle to 120 degree at horizontal line, 60 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion;
    5) Can repair each led lamps, so the cost of maintain is lower, and easy to repair.

    LED Screen Parameter:

    led board
    Pitch size 16mm
    Module size 256mm*128mm
    Module pixel(dots) 16*8
    Pixel configuration 1Red,1Green,1Blue SMD 3-in-1
    LED chip Silan/Opistal
    Color scale 65536degree/1.07 billion colors
    Pixel density 3906 pixels/square meter
    View angle(H/V) 120/120degree
    Brightness 6000cd/sqm
    Brightness adjustment 100level automatic or manual
    View distance 5--80m
    Power consumption 100-1200W/sqm
    Net weight 55kg/square meter
    Operating temperature —25°C~+60°C
    Operating humidity 10%—95%RH
    Life time ≥100,000hours
    Out of control dot ≤3/10,000
    Whole Display Flatness ≤1mm Juncture
    Exchange frame speed >150frames per second
    Refresh frame frequency 600Hz
    Control distance Cat. 5: 120m (without repeater), single mode fiber:20km,multi mode fiber: 500m
    Power 110V/220V 50/60Hz
    Operating system Windows98/Me/2000/Xp
    Drive mode constant current driving, static scan
    Display mode VGA640X480—VGA1600X1024
    Protections for outdoor display IP65 for front, IP64 for rear
    Maintenance way rear access, haging installation
    Accepting signal PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI

    Digital billboard truck mobile led display , led mobile advertising trucks for sale



    Digital billboard truck mobile led display , led mobile advertising trucks for sale





    Packaging & Shipping

    Packaging: Naked, waxing on ro-ro or bulk ship or by 20GP, 40GP, 40HQ, 40FR and so on;

    Payment :30% deposit by T/T,before leaving factory should pay the 70% balance by T/T;

    Free training:3 days on-site complete technical training in our Shenzhen
    factory or internet on-line teamviewer via remote control or skype on line
    communication,what's more,we have valuable users' manual to guide for
    debugging and installing successfully.
    Installation service:
    The seller should provide on the spot installation instruction service for the
    buyer, including:
    A, To check whether the bracket and frame are in conformity with the technical
    requirements of the structure scheme the seller provided
    B, To instruct the buyer’s technicians to install the LED module cases and
    connection among those cases
    C, To experiment and adjust the whole panel, examine and repair the
    defective devices, guarantee panel in secure operation.
    D, To train the buyer’s technicians.
    For spot installation and train in foreign country, the service is 100 usd/day,
    and the buyer must pay our technician’s living and traffic fee during the installation
    period.


    Trade terms:
    1. Hardware: LED display and video controlling system
    2. Technical material: English version user manual, installation manual And
    maintenance manual
    3. Service:Provide free technology support by phone and e-mail 7 years
    guarantee
    4. Delivery: Approx 3-12 working days
    5. Packing: Anti-shaking wooden package or Air Flight Case.
    6. Transportation: By sea or air or Express

    Hope we can further together and work together



    Loading port & border:
    Shanghai,Tianjin,Guangzhou,Qingdao,mainly shenzhenErenhot,Horgos or according to your order;

    The whole set or just the screen, choose by yourself!
