P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving

P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving

  • P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving
  • P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving
P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving
Product Details:
Place of Origin: China
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P10
Payment & Shipping Terms:
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after receive your payment
Payment Terms: T/T or western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Product Name: The Stadium Led Display Module Size(W * H): 320mm*160mm
Standard: CE/ROHS/FCC/ISO2001 Tube Chip Color: Full Color
Pixel Pitch: 10mm Resolution(W*H): 32dots*16dots
Cabinet Material: Steel Encapsulation: DIP
High Light:

perimeter led display

,

led perimeter advertising boards

P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving



SCXK Elecronic Co., Ltd is a high technology enterprises specializes in manufacturing, selling and serving LED display, intelligent electronic product.the use of materials and accessories are from the world's top listed companies. We have a deep understanding of user needs, for the LED display and LED lighting has the advantages of energy saving and durability. Our product have obtained CE and ROHS certification.



Features:



1. High brightness. Use DIP LEDs, keeps the display content visible even if facing the strong sunshine directly.

2. With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.

3. Waterproof design, completely outdoor use.

4. Easy for assembling and connection with the connector added.

5. High color uniformity and clear image can bring you a vivid audio visual effect.

6. Both front and rear access are available.

7. Good LED Chips, with large viewing angle, lowe power consumption and good color uniformity.

8. Easy for maintenance.

9. Good quality raw material, accurate technique and careful inspection insures the high quality of led display.

10. Different shape and size can be made according to your requirement.

11. Items: BESD-OFP10, BESD-OFP12, BESD-OFP12.5, BESD-OFP16, BESD-OFP20, BESD-OFP25 etc.

12. Widely used for building, shopping mall, cinema, station, stadium, plaza, street etc.



After-sale service


Technical service


(1) System and product training in the pre construction, in order to have a thorough understanding of products;
(2) Provide installation training, be able to achieve the system installation and maintenance;
(3) After the project will be application training, make users grasp the use of the systematic hardware skillfully ;
(4) Users change , free training for new staff;
(5) We are responsible for the training of your staff's use;



Spare parts warranty period Configuration Guidelines


(1) Adequacy: With the specific equipment, spare parts allocation adequate, ensure replacement in the first time of equipment failure;
(2) Necessity: On the basis of previous maintenance experience, we configure the spare parts are the key parts of the equipment, so as to ensure the economic allocation;
(3) Economic practicality: In order to deal with the fault in the shortest time, we configure the spare parts are complete module or unit, through our training, the owners can easily replace the spare parts, so as to ensure the normal operation of the system.





parameter



Product Linso Display Application in sports stadium
Application Outdoor
Pixel pitch 10mm 16mm 20mm
LED type DIP346 DIP546 DIP546
Module size 160X160 256X128 320X160
Module resolusion 16X16 16X16 16X8
Pixel configuration 1R1G1B 2R1G1B 2R1G1B
Pixel density 10000dot/sqm 3906dot/sqm 2500dot/sqm
Best viewing angle 110°/ 75° 110°/ 75° 110°/ 75°
Best viewing distance 10m-100m 10m-150m 10m-150m
Protection IP65 IP65 IP65
Average power consumption 550W/sqm 700W/sqm 550W/sqm
Max power consumption 1450W/sqm 1500W/sqm 1300W/sqm
Cabinet weight 45kg/sqm 45kg/sqm 45kg/sqm
Driver 1/4scan Constant current Constant current Constant current
Frame frequency: ≥60hz/s ≥60hz/s ≥60hz/s
Refresh frequency ≥2000hz/s ≥3500hz/s ≥3500hz/s
Brightness ≥8000cd/sqm ≥8500cd/sqm ≥7500cd/sqm
Storage temperature: -40°C~+85°C -40°C~+85°C -40°C~+55°C
Operated temperature -20°C~+55°C -20°C~+55°C -20°C~+55°C
Malfunction dot rate <0.0001 <0.0001 <0.0001
Life >10,000hours >10,000hours >10,000hours



P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving 0



♦ Our advantages

1. OEM service,No MOQ

2. Easy installation,regular items in Stocks

3. Offering free design drawing as requested.

4. Remote controlling and adjusting are available.

5. Wooden case or flight case,you are the boss.

6. Your reply will be replied within 24 hours.

7. Fast delivery: Usually 6-8 working days

8. Excellent R&D team,factory Price and assure you quality goods.



♦ Production process:



1) Incoming Inspection→2)SMD→3)Plug-in

→4) Wave Soldering→5)After Welding→6)Testing

→7) Semi Finished Aging→8)Module Assembly

→9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing



♦ Packaging and shipping






P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving 2

we can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.

we can choose the best shippment which is convenient to you!

SCXK group can give you the short delivery time and With the large production ability ,

you can feel free about this . By air ,by train, by sea?





♦ Why choose us:



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.

P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving 3



♦ Applications



--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.



♦ Frequently Asked Questions



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.



P16 P20 DIP Stadium LED Display outdoor , perimeter led screen Energy saving 4
