Noiseless Slim Outdoor Full Color Led Display Hd / Lifting Square Led Van Screens Wall

Noiseless Slim Outdoor Full Color Led Display Hd / Lifting Square Led Van Screens Wall

  • Noiseless Slim Outdoor Full Color Led Display Hd / Lifting Square Led Van Screens Wall
  • Noiseless Slim Outdoor Full Color Led Display Hd / Lifting Square Led Van Screens Wall
  • Noiseless Slim Outdoor Full Color Led Display Hd / Lifting Square Led Van Screens Wall
  • Noiseless Slim Outdoor Full Color Led Display Hd / Lifting Square Led Van Screens Wall
Noiseless Slim Outdoor Full Color Led Display Hd / Lifting Square Led Van Screens Wall
Product Details:
Place of Origin: China ,Guang Dong
Brand Name: Shichuangxinke
Certification: CE RoHS FCC CCC TUV UL
Model Number: SCXK-P20
Payment & Shipping Terms:
Minimum Order Quantity: 1 square meters
Price: USD 400-750 square meters
Packaging Details: wooden box flight case, wooden case, carton, it is up to you.
Delivery Time: 7-10 working days after deposit payment received
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000sqm per month
Contact Now
Detailed Product Description
Resolution/mm: 20 Pixel Configuration: 1R1G1B
Scanning Mode: Static Full Color Module Size: 320x160mm
Cabinet Size: 1280x960mm Certificates: CE RoHS FCC CCC UL
Application: Stadium,airport,shopping Mall,street Advertising Material: Aluminum
Warranty: 3-5 Years
High Light:

full color outdoor led display

,

outdoor full color led screen



Noiseless Slim Outdoor Full Color Led Display Hd / Lifting Square Led Van Screens Wall





Why Choose Us



1. Competitive Price
We are middle-sized Chinese local factory, maybe you can see that from our so Chinese name of "SCX", unlike the internationalized name of foreign trade company. Besides, we control our cost very well and don't have huge management cost like top companies, so that we can give the real benefits to our customers.

2. Close Relationships with Raw Material Providers
For our bosses have been in the key positions at the top led display factory since 2009, we have very close and strategic relationship with the raw material providers, which support the stable quality of our products.

3. Quality Control
From raw materials to finished product, from design to produce, we control all steps, which are the guarantee of the quality and reliability.









Features:
1) Relatively low cost (factory)
2) New design, suitable for outdoor live show
3) High brightness, high definition of displaying image.
4) Neither flick nor color blocks.
7) Quick and Easy Installation in 5 Seconds/cabinet.
8) Maximum support 50pcs hanging in a column.
9) Quality advantage: From material to finished product, from design to produce, we control all steps, which are the guarantee of the quality and reliability.




Specifications :

outdoor DIP P20
Resolution/mm 20
Pixel configuration 1R1G1B
Pixel density/pixels/m² 2500/m²
Module resolution 16x8
Module size/mm 320x160mm
View distance 14-300m
Single point brightness adjust Can be added
Single point color adjust Can be added
White balance brightness >7500cd/㎡
Color temperature 6500K-9500K
Horizontal view angle 120(degrees)
Vertical view angle 60(degrees)
Signal Process bit 10 or 16bit
Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode Constant driving current
Scanning mode static full color
Frame rate 60Hz
Refresh frequency >3000Hz
Control mode Computer synchronous
Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point <1/10000
Working hours ≥72hours
Mean Time Between Failure >5000hours
Life time 100000hours
Life-all-white(brightness halving) 50000hours
Environment temperature range Operating temperature range: -20-45℃
Self-check technology LED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoring Remote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environment WindowsNT,Windows1999,WindowsXP
Luminous point width between centres Deviation<3%
Brightness uniformity <10%
Color uniformity(chromaticity coordinate) ±0.003
Power supply request AC85-264V(50Hz-60Hz)
Contrast (1000:1)
System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working) working:10-95%
Humidity(storing) storing:10-95%





Trade Terms:
1).Payment: T/T ,ususally 40% prepayment before production, 60% balance to be paid before delivering,it also change according to total quantity
2).Production lead time less 20 sqm: 8-15days, more than 50 sqm:30days
3).Sample can be deliveried within 3days
4).Shipping port: Shenzhen, Mainland China
5).Discounts are offered based on order quantities
6).MOQ:1 sqm/1pcs
