Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/ISO/UL |
| Model Number: | P6 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after receive your payment |
| Payment Terms: | T/T or western Union |
| Supply Ability: | 5000sqm per month |
| Product Name: | Outdoor P6 Pillar Led Display | Module Size(W * H): | 192mm*192mm |
|---|---|---|---|
| Standard: | CE/ROHS/FCC/ISO2001 | Led Chip: | Epistar |
| Pixel Pitch: | 6mm | Resolution(W*H): | 32dots*32dots |
| High Light: | full color outdoor led display,outdoor full color led screen |
||
high definition outdoor p6 full color video function pillar led display
SHENZHEN SCXK ELECTRONICS CO., Ltd delivers customized event led projects that connect our clients to their audiences in a meaningful way.founded in 2005 specialized in Flexible led display, Transparent led screen and Rental LED display. Offer architects, designers and property owners a digital surface not previously available. Now with a wide range of resolution options, flexible form factors, light weight, low power and silent operation, developing negligible heat and delivering exceptional sustainability results, LED technology is transforming property precincts like never before.
Main products: Curved LED screen, Transparent LED screen, Rental LED screen.
Product Specifications
| LED tube chip parameters | ||||||
| Packaging | Color | Brand | Model | Brightness | Wave length | Quantity |
| 146 | R | Epistar | 9mil | 800-900 | 730-800 | 1 |
| G | Epistar | 8x10mil | 1000-1100 | 900-1000 | 1 | |
| B | Epistar | 8x10mil | 230-260 | 230-260 | 1 | |
| LED module parameters | |||
| Pixels pitch: | 6.0mm | Pixel density: | 27777dot/m2 |
| Pixel configuration: | 1R1G1B | Module pixels: | 32*32=1024dots |
| Module size: | 192mm*192mm | Module weight: | 0.3KG |
| Configuration feature: | Integrated Light/Driver | Frame material: | Polycarbonate(PC) |
| Input voltage: | AC 4.8-5.5V | Max current: | 6.0A±0.1A |
| Module power consumption: | 30W | Driver mode: | 1/8 scan |
| LED cabinet parameters | |
| Standard cabinet size: | 576*576mm |
| Cabinet pixel: | 96*96=9216 dots |
| Cabinet square: | 0.33m2 |
| Cabinet weight: | 40KG |
| Max power consumption: | 450W |
| Average power consumption: | 250W |
| LED display parameters | |||
| Brightness: | ≥6500cd/m2 | Brightness homogeneity: | ≥0.95 |
| Best horizontal view angle: | 100±8° | Best vertical view angle: | 70±5° |
| Best view distance: | ≥6.0m | Blind spot rate: | ≤0.0003 |
| Max power consumption: | 600W/m2 | Application condition: | intdoor |
| System control parameters | |||
| Gray scale: | each R, G, B - 65536 | Color | 16777216 kinds |
| Repetition rate: | ≥60 frame/second | Refresh rate: | ≥1400Hz |
| Control method: |
PC control, video synchronization |
Brightness adjusting: | 256 auto/manual |
| Input signal: | DVI/VGA, RGBHV, S-VIDEO, HDTV and so on | ||
| System working features | |||
| Lifespan: | ≥100,000 hours | MTBF: | ≥10,000 hours |
| Attenuation rate: | ≤15% 3 years working | Out of control dots: | 0 |
| Discrete control dot: | 0 (before shipment) | Blind spot rate: | 0 (before shipment) |
| Working temperature: | -20 ~50 °C | Working humidity: | 10%~90%RH |
| Protection feature: |
over-heat, over-load, image complement, overcurrent, overvoltage, anti- thunder (optional) |
||
Packaging Detail: Fumigation-free plywood box, airflight case, Carton, etc.
Note: different payment methods can be provided according to different countries.
