Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | CHINA |
| Brand Name: | SCX |
| Certification: | CB,UL，CE |
| Model Number: | outdoor p6 |
| Minimum Order Quantity: | 6 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden case，flight case |
| Delivery Time: | 4-16 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5300 sqm month |
| Waterproof: | IP68 | Brightness: | 6500nit |
|---|---|---|---|
| AC: | Not Need | Cabinet Size: | 960x960mm |
| Refresh Rate: | 3840hz | Leds: | Nationstar |
| High Light: | P6 IP68 Outdoor Digital Signage Displays,3840hz Outdoor Digital Signage Displays,6500nit Outdoor Led Advertising Display |
||
P6 Waterproof IP68 Outdoor Digital Signage Displays For Advertisement
Product Advantage
1. Light ball:
Our company adopts high quality SMD3535 , from raw material processing to encapsulation technology to quality control, we are all more trustworthy than market three without products !
2. Chip:
The solid crystal, gold wire bonding, precision testing of the leading LED packaging technology, equipping with advanced automatic production line and production equipment, the international leading quality inspection and reliability test equipment, guaranteeing the effect of chip quality LED display screen refresh rate is higher.
3. Border:
From details to ensure product quality.The frame thickness is 0.5mm above the market, which is more durable and durable.Surface level not to drop paint, work fine and more beautiful.
4. Factory strength:
Our company focus on full color LED display screen and LED technology industry production, sales and service, our company has the industry advanced, complete automatic rapid assembly lines, production capacity output high on industry.Worldwide commitment and fulfillment of user professional services and guidance.
5. High gray high brush:
The sun is still bright and bright picture, the display is natural and true, each module has been through the point brightness and chroma correction, brightness and color uniformity.
High waterproof and dustproof rating (before IP65), strong anti-seismic ability to adapt to extreme weather
Flatness: the whole screen: ≤ ± 1mm patchwork between the module: ≤ 1mm
Viewing distance: 8-200m, the display is clearly visible
Image adjustment: Contrast / tone adjustment / single mode group brightness adjustment
♦ Product specification
|
outdoor SMD P6 |
||||||||||||||
|
Resolution/mm |
6 |
|||||||||||||
|
Pixel configuration |
1R1G1B |
|||||||||||||
|
Pixel density/pixels/m² |
27778/m² |
|||||||||||||
|
Module resolution |
32*32 |
|||||||||||||
|
Cabinet size/mm |
576x576 |
|||||||||||||
|
View distance |
5-400m |
|||||||||||||
|
Single point brightness adjust |
Can be added |
|||||||||||||
|
Single point color adjust |
Can be added |
|||||||||||||
|
White balance brightness |
>8000cd/㎡ |
|||||||||||||
|
Color temperature |
6500K-9500K |
|||||||||||||
|
Horizontal view angle |
120(degrees) |
|||||||||||||
|
Vertical view angle |
60(degrees) |
|||||||||||||
|
Signal Process bit |
10 or 16bit |
|||||||||||||
|
Grey process |
1024x1024x1024 16834x16834x16834 65536x65536x65536 |
|||||||||||||
|
Control distances |
Internet cable:100m, multimembrane:500m, monofilm:2km |
|||||||||||||
|
Driving mode |
Constant driving current |
|||||||||||||
|
Scanning mode |
(1/4) |
|||||||||||||
|
Frame rate |
60Hz |
|||||||||||||
|
Refresh frequency |
>4200Hz |
|||||||||||||
|
Control mode |
Computer synchronous |
|||||||||||||
|
Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
|||||||||||||
|
Out of control point |
<1/10000 |
|||||||||||||
|
Working hours |
≥72hours |
|||||||||||||
|
Mean Time Between Failure |
>5000hours |
|||||||||||||
|
Life time |
100000hours |
|||||||||||||
|
Life-all-white(brightness halving) |
50000hours |
|||||||||||||
|
Environment temperature range |
Operating temperature range: -20-45℃ |
|||||||||||||
|
Maximum power:/㎡ |
<900W |
|||||||||||||
|
Average power:/㎡ |
<350W |
|||||||||||||
|
Self-check technology |
LED spot self-check, communications check, power check, temperature monitor(need customization) |
|||||||||||||
|
Remote monitoring |
Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
|||||||||||||
|
Software environment |
WindowsNT,Windows1999,WindowsXP |
|||||||||||||
|
Luminous point width between centres |
Deviation<3% |
|||||||||||||
|
Brightness uniformity |
<10% |
|||||||||||||
|
Color uniformity(chromaticity coordinate) |
±0.003 |
|||||||||||||
|
Power supply request |
AC85-264V(50Hz-60Hz) |
|||||||||||||
|
Contrast |
(1000:1) |
|||||||||||||
|
System protection |
Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
|||||||||||||
|
Humidity(working) |
working:10-95% |
|||||||||||||
|
Humidity(storing) |
storing:10-95% |
|||||||||||||
Led Screen video wall
♦ Production process:
1) Incoming Inspection→2) SMD→3) Plug-in
→4) Wave Soldering→5) After Welding→6) Testing
→7) Semi Finished Aging→8) Module Assembly
→9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
FAQ
1. How long could i receive the inquiry reply ?
A: You will get a reply within 24 hours.
2.What kind of led display do you offer ?
A: Different product offer different time frame warranty, but all product here we offer 1 year at least warranty
3.How is the after sales service ?
A: We have a professional team which is in all around the world , also a service hot-line dealing with your complains
and feedback. We also offer 24-hour online service to help you solving problems
4.How long will it take to deliver goods ?
A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after
we get your payment.
