* Weight: 7.5kg/pcs
* Application: TV studio, stage background, party, show room, conference center, exhibition, bar, museum, church...
Place of Origin: | China |
Brand Name: | SCX |
Certification: | CB,CE,UL |
Model Number: | indoor p3.91 |
Minimum Order Quantity: | 16sqm |
---|---|
Price: | negotiation |
Packaging Details: | wooden case,flight case |
Delivery Time: | 7-16 working days |
Payment Terms: | L/C, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 4600 sqm month |
Specification: | Video Wall | Cabinet Weight:: | 7.5kg |
---|---|---|---|
Cabinet Material:: | Die-casting Aluminum | Brightness: | 5000-5500 Nits |
Refresh Rate (Hz): | 3840 | Life Span: | 100000hours |
High Light: | Indoor Portable LED Display,3840hz Portable LED Display,5500nits Stage Led Screen |
Features
1, Seamless connection.
2, Special design for the mask to realize higher contrast and larger viewing angle.
3, Signal backup and power backup.
4, Brightness and chromaticity calibration.
Specification
Pixel Pitch | 3.91mm |
Pixel Density | 65536dots/sqm |
Color Configuration | 1R1G1B |
LED Package | SMD2121 |
Module Size | 250mm x 250mm |
Module Resolution | 64dots x 64dots |
Drive Mode | 1/16 Scan |
Cabinet Material | Die casting Aluminum |
Led Color | Black |
Standard Cabinet Size | 500mm x 1000mm |
Cabinet Weight | 12KG |
Brightness | ≥1300 cd/sqm, adjustable by software |
Viewing Distance | 4m-40m |
Viewing Angle | H: 160°; V:160° |
Refresh Rate | 3840HZ, adjustable by software |
Frame Rate | 120frame/s |
Grey Scale | 16.7M colors(Synchronized) |
Color Temperature | R.G.B brightness 256 level adjustable |
Power Input | AC110V/ 220V ±10%, 50HZ |
Max Power Consumption | 800W/sqm |
Ave. Power Consumption | 300W/sqm |
Storage Temperature | -30℃~+70℃ |
Working Temperature | -20℃~+50℃ |
Blind Spot Rate | <1/10000 |
MTBF | >10,000 Hours |
Life Span | >100,000 Hours |
Waterproof Level | IP43 |
Operating Humidity | 10%~90% RH |
Control Method | Synchronous, Asynchronous, 3G,WIFI,USB |
PC Display Resolution | 1280x1024 |
Control PC | With DVI Graphic card |
Operating System | Win 98, Win2000, XP, Win7, Win8,Win10 |
Video Signal Mode | RF, S-Video, RGB, RGBHV, YUV, YC etc |
Certificate | CE, RoHS |
Contact Person: BOSCO
Tel: +8615177780539
