Minimum Order Quantity:	14sqm
Price:	negotiation
Packaging Details:	wooden case，flight case
Delivery Time:	5-7 working days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	4000 sqm per sqm

Brightness:	≥7000cd/m²	Control System:	Synchronous Or Asynchronous
Display Type:	Outdoor Full Color LED Display	Gray Scale:	14bit
IP Rating:	IP65	Input Voltage:	AC 110V/220V
Pixel Density:	10000-30000 Dots/m²	Power Consumption:	Average: 350W/m², Max: 900W/m²
Refresh Rate:	≥1920Hz	Working Temperature:	-20℃~+60℃
High Light:	ip65 outdoor advertising led display board , hd outdoor advertising led display board , p3 outdoor led video wall

OF/OFR	OF2.5	OF3	OF3.076	OF3.91	OF4	OF4.81	OF5
Pixel Pitch(mm)	2.50	3.00	3.08	3.91	4.00	4.81	5.00
Pixel Matrix Per Sq.m	160000	111111	65436	65436	62500	62500	40000
Pixel Configuration	SMD1415	SMD1415	SMD1415	SMD1921	SMD1921	SMD1921	SMD1921
Brightness (nits)	5000	1800	5000	4000	5000 5500	4000	5500
Scan	1/16	1/16	1/13	1/16	1/10 1/8	1/13	1/8
Module Dimension	160x160mm	192x192mm	320x160mm	250x250mm	320x160mm 256x128mm	250x250mm	320x160mm
Cabinet Weight	46kg / 101lb (Iron)	46kg / 101lb (Iron)	45kg / 99lb (Iron)	44kg / 97lb (Iron)	44kg / 97lb (Iron)	43kg / 95lb (Iron)	43kg / 95lb (Iron)
Power Con. (Max / Avg)	900/ 180 w/sq.m
Cabinet Dimension	960x960mm (Cabinet size can be changed according to module size)
IP Rate	IP65
Service Access	Rear
Refresh Rate (HZ)	>1920
Grey Scale (bit)	16bit
Viewing Angle (H/V)	140/140
Input Voltage (AC)	110V/240V

OF/OFR	OF6	OF6.6	OF8	OF10S	OF10D	OF16S	OF16D
Pixel Pitch(mm)	6.00	6.67	8.00	10.00	10.00	16.00	16.00
Pixel Matrix Per Sq.m	27777	22500	15625	10000	10000	8000	10000
Pixel Configuration	SMD3535	SMD2727	SMD3535	SMD3535	DIP346	SMD3535	DIP346
Brightness (nits)	5500	5500	6500	6500	1000	8000	10000
Scan	1/8	1/6	1/3	1/2	1/2	1/1	1/1
Module Dimension	192x192mm	320x160mm	320x160mm	320x160mm	320x160mm	256x256mm	256x256mm
Cabinet Weight	42kg / 93lb (Iron)	42kg / 93lb (Iron)	41kg / 90lb (Iron)	40kg / 88lb (Iron)	40kg / 88lb (Iron)	46kg / 101lb (Iron)	46kg /101lb (Iron)
Power Con. (Max / Avg)	900/ 180 w/sq.m
Cabinet Dimension	960x960mm (Cabinet size can be changed according to module size)
IP Rate	IP65
Service Access	Rear
Refresh Rate (HZ)	>1920
Grey Scale (bit)	16bit
Viewing Angle (H/V)	140/140
Input Voltage (AC)	110V/240V

Hd Ip65 Outdoor Advertising Led Display Board

ip65 outdoor advertising led display board
