Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | shenzhen,China |
| Brand Name: | SCX |
| Certification: | CE,CB,IEICC,FC |
| Model Number: | indoor p2.5 |
| Minimum Order Quantity: | 10 sqm |
|---|---|
| Price: | negotiation |
| Packaging Details: | wooden case，flight case |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 4900 sqm per month |
| Brightness: | 1000-1200nits | Control System: | Synchronization |
|---|---|---|---|
| Display Type: | Indoor Full Color LED Display | Gray Scale: | 14bit |
| Input Voltage: | AC220V/50HZ | Lifespan: | ≥100000hrs |
| MTBF: | ≥10000hrs | Pixel Configuration: | 1R1G1B |
| Viewing Angle: | H:140°/V:140° | Warranty: | 2 Years |
| High Light: | p2.5 indoor full color led display,1R1G1B indoor full color led display,p2.5 indoor full color led screen |
||
novastar p2.5 indoor advertising hd led video wall diecasting cabinet 640x480 displays p2.5 led screen
| Pixel Information | Pixel Pitch | 2.5mm |
| Pixel Density | 160000dots/m2 | |
| Pixel Configuration | SMD2121 | |
| LED Wavelength | Red:615 nm - 635 nm | |
| Green:520 nm - 535 nm | ||
| Blue:465 nm - 475 nm | ||
| LED Module | Size(mm) | 320(Width) * 160(Height) |
| Resolution | 128 (Width) * 64(Height) | |
| Power | Input Voltage | 100-240V AC, 50/60Hz |
| Max Power Consumption | 800 Watt/sqm | |
| Avg. Power Consumption | 350 Watt/sqm | |
| Brightness | 5000cd/m2 | |
| Brightness Uniformity | Luminance Discrepancy < 5% | |
| Best Viewing Angle | Horizontal:140°, Vertical:140° | |
| Ambient Conditions | Temperature Range | Working:-20deg. to +65deg |
| Operating Humidity | 10%-90%RH | |
| Ingression Protection Grade | IP40 | |
| Processing | Scanning Mode | 1/32scan |
| Refresh Rate | >2460Hz, Adjustable(depends on control system) | |
| Signal Input | DVI, Composite Video for Live Video | |
| Supported Networking | Through LAN/WAN, RS 232/RS485 | |
| Controller | Linsn or Nova | |
All module products will be checked more than 3 times in production
Different module carton have different size and quantity, before you place order,pls ask us
Q1. Can I have a sample order? A: Yes, we welcome sample order to test and check quality. Q2: What LED screen size you can do? A: One LED panel has several sizes for option: 640x480mm, 640x640mm, 320x640mm, 320x480mm, which can meet the needs of flexible sizes splicing. Q3: How to control the LED screen? A: We can provide the control system from well-known Novastar. Q4: Can you provide installation structures? A: Yes, we can provide installation structures for various installations. Q5: Do you test your LED screen before shipping? A: Yes, we do 100% product ageing test for 72 hours before package and shipping. Q6: What will you do if we have problems related to installation, configuration and use? A: Our after-sale service team will provide service to solve all the problems, until the screen can work normally. Q7. What is your terms of delivery? A: EXW, FOB, CIF, CFR, DDP, DDU, customer specified freight forwarder or negotiable mode of transport.
