Novastar P2.5 Indoor Full Color Led Display Advertising Hd 640x480

Name: Novastar P2.5 Indoor Full Color Led Display Advertising Hd 640x480
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: indoor p2.5
Price: 10000 USD
Availability: InStock

Brand Name:	SCX
Model Number:	indoor p2.5
MOQ:	10 sqm
Price:	negotiation
Payment Terms:	T/T, Western Union
Supply Ability:	4900 sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

shenzhen,China

Certification:

CE,CB,IEICC,FC

Brightness:

1000-1200nits

Control System:

Synchronization

Display Type:

Indoor Full Color LED Display

Gray Scale:

14bit

Input Voltage:

AC220V/50HZ

Lifespan:

≥100000hrs

MTBF:

≥10000hrs

Pixel Configuration:

1R1G1B

Viewing Angle:

H:140°/V:140°

Warranty:

2 Years

Packaging Details:

wooden case，flight case

Highlight:

p2.5 indoor full color led display

1R1G1B indoor full color led display

p2.5 indoor full color led screen

Product Description

novastar p2.5 indoor advertising hd led video wall diecasting cabinet 640x480 displays p2.5 led screen

Product Description

Pixel Information	Pixel Pitch	2.5mm
	Pixel Density	160000dots/m2
	Pixel Configuration	SMD2121
	LED Wavelength	Red:615 nm - 635 nm
		Green:520 nm - 535 nm
		Blue:465 nm - 475 nm
LED Module	Size(mm)	320(Width) * 160(Height)
LED Module	Resolution	128 (Width) * 64(Height)
Power	Input Voltage	100-240V AC, 50/60Hz
	Max Power Consumption	800 Watt/sqm
	Avg. Power Consumption	350 Watt/sqm
Brightness	5000cd/m2
	Brightness Uniformity	Luminance Discrepancy < 5%
	Best Viewing Angle	Horizontal:140°, Vertical:140°
Ambient Conditions	Temperature Range	Working:-20deg. to +65deg
	Operating Humidity	10%-90%RH
	Ingression Protection Grade	IP40
Processing	Scanning Mode	1/32scan
	Refresh Rate	>2460Hz, Adjustable(depends on control system)
	Signal Input	DVI, Composite Video for Live Video
	Supported Networking	Through LAN/WAN, RS 232/RS485
	Controller	Linsn or Nova

Production Flow

All module products will be checked more than 3 times in production Novastar P2.5 Indoor Full Color Led Display Advertising Hd 640x480 4

Shipping&Package

Different module carton have different size and quantity, before you place order,pls ask us Novastar P2.5 Indoor Full Color Led Display Advertising Hd 640x480 5

Production Assemblem

Novastar P2.5 Indoor Full Color Led Display Advertising Hd 640x480 7 Q1. Can I have a sample order? A: Yes, we welcome sample order to test and check quality. Q2: What LED screen size you can do? A: One LED panel has several sizes for option: 640x480mm, 640x640mm, 320x640mm, 320x480mm, which can meet the needs of flexible sizes splicing. Q3: How to control the LED screen? A: We can provide the control system from well-known Novastar. Q4: Can you provide installation structures? A: Yes, we can provide installation structures for various installations. Q5: Do you test your LED screen before shipping? A: Yes, we do 100% product ageing test for 72 hours before package and shipping. Q6: What will you do if we have problems related to installation, configuration and use? A: Our after-sale service team will provide service to solve all the problems, until the screen can work normally. Q7. What is your terms of delivery? A: EXW, FOB, CIF, CFR, DDP, DDU, customer specified freight forwarder or negotiable mode of transport.
