High Brightness 1/8 Scan P6 192mm X192mm Outdoor Full Color Led Display For Advertising

high brightness 1/8 scan p6 192mm x192mm outdoor full color led display for advertising

Product feature

(1) Suport multiplied file formats, such as AVI, MOV, MPG, DAT, VOB are comprehensive, and also we have three display mode as VGA+VIDE and VGA. There are also interfaces for Sound signal and video signal, including CVBS, S-Video, VGA, DVI, .



(2) Show all kinds of word, text, graph, picture, video, 2-dimention, 3-dimention cartoon and other information with your PC does synchronously.



(3) Can be connected with PC and the web net and show the content, and also can be controlled remotely via VPM+ADSL. (One-Sever-AnyClients supported)



(4) Can be used outdoor in all kinds of weather, and excellent capability of antisepsis, waterproof.







Our Service



1)Training after order

After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment



2) Installation and debugging

BESD could send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.



3) Warranty

Warranty: 2 years warranty, lifetime maintenance

Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.



4) Maintenance

Maintenance principles: response in time, solve problems asap and ensure the use.

Maintenance period: In the maintenance period of the led display body, free of all maintenance charges

After maintenance period, only charge the material cost and labor cost.



Resolution/mm	6
Pixel configuration	1R1G1B
Pixel density/pixels/m^2	27778/m^2
Module resolution	32dotsx32dots
Module size/mm	192mmx192mm
View distance	4-300m
Single point brightness adjust	adjustable
Single point color adjust	adjustable
White balance brightness	5000 cd/m^2
Color temperature	6500K-9500K
Horizontal view angle	120(degrees)
Vertical view angle	60(degrees)
Signal Process bit	10 or 16bit
Grey process	1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distances	Internet cable:100m, multimembrane:500m, monofilm:2km
Driving mode	Constant driving current
Scanning mode	1/8 scan
Frame rate	60Hz
Refresh frequency	>3000Hz
Control mode	Computer synchronous
Brightness adjusted range	Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss
Out of control point	<1/10000
Working hours	≥72hours
Mean Time Between Failure	>10000hours
Life time	100000hours
Life-all-white(brightness halving)	100000hours
Environment temperature range	Operating temperature range: -20-45℃
Maximum power:/^2	<700W
Average power:/^2	<200W
Self-check technology	LED spot self-check, communications check, power check, temperature monitor(need customization)
Remote monitoring	Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization)
Software environment	WindowsNT,Windows1999,WindowsXP
Luminous point width between centres	Deviation<3%
Brightness uniformity	<10%
Color uniformity(chromaticity coordinate)	±0.003
Power supply request	AC85-264V(50Hz-60Hz)
Contrast	(1000:1)
System protection	Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)	working:10-95%
Humidity(storing)	storing:10-95%

Product Name	outdoor p6 mm SMD Full color led module With 32dots x 32dots Resolution
Service	Your inquiry will be reply within 12 hours.
Brand	SCXK
Material	Stainless, aluminum ,steel, epoxide
Item	Indoor P2 P2.5,P3,P3.91P4,P5,P6,P7.62 Outdoor p3.91 P4 ,P5 P6,P8,P10, ect.
Feature	High brightness, good resolution, working stable , easy installation.
Grade	IP43-IP65
Driving mode	1/8
Stock	Regular items of led display have stocks.
Color temperature	6500-9500K
Packing Method	Flight case &Plywood case or Customized Packing
Power supply request	AC85-264V(50HZ-60HZ)
Delivery Time	Within 7-30 days according to your required size & quantity.
Using Range	Shopping mall,bank,bus station, train station, center of downtown, airport, school, factory, bus, taxi, and etc.



Order Procedure



Negotiation---First solution recommended---Finalize all the details---30%deposit in advance or full deposit---

Start production---Pay the balance---shipment by DHL--provide tracking number---feedback.



♦ Packaging and shipping







we can receive all kinds of transportation. and the shippment term. FOB and CIF. EXW and so on.

we can choose the best shippment which is convenient to you!

SCXK group can give you the short delivery time and With the large production ability ,

you can feel free about this . By air ,by train, by sea?





♦ Applications



--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.



♦ Why choose us:



Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.





♦ Frequently Asked Questions



What kind of payment terms you can accept ?

We can accept T/T and Western Union.



What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.



What is your delivery time ?

Within 7-35 days according to your area and quantity.



Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.
