Home ProductsSMD LED Screen

Customized Flexible Led Indoor Display 3840hz HD P3.91 Full Color 1200cd/㎡ Brightness

Customized Flexible Led Indoor Display 3840hz HD P3.91 Full Color 1200cd/㎡ Brightness

  • Customized Flexible Led Indoor Display 3840hz HD P3.91 Full Color 1200cd/㎡ Brightness
  • Customized Flexible Led Indoor Display 3840hz HD P3.91 Full Color 1200cd/㎡ Brightness
Customized Flexible Led Indoor Display 3840hz HD P3.91 Full Color 1200cd/㎡ Brightness
Product Details:
Place of Origin: China
Brand Name: SCX
Certification: CE,ROHS,FCC,SASO
Model Number: P3
Payment & Shipping Terms:
Minimum Order Quantity: 1 SQM
Price: USD 1000-10000
Packaging Details: Wooden Case , Size: 60x62x50cm, Wooden Case, Size:70x65x55cm
Delivery Time: 10-15 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 sqm per month
Contact Now
Detailed Product Description
Led Module: 250*250mm Pixel Density: 65410 Dots/sqm
Brightness: ≥1200cd/㎡ Scanning: 1/16 S
Waterproof: IP34
High Light:

led display smd

,

smd led display

Over 3840hz Popular Led Screen HD P3.91 Indoor Full Color Led Display Customized Flexible Led Indoor Display





Features



1. LED Chip: Supplied by Nichia of Japan & Cree of USA & Epistar of Taiwan or other high strictly

selected LED chip, assure high definition show effect.

2. Wide viewing angle 120/160°, perfect and impressive viewing effect.

3. High quality IC selection: MBI5024/5035/5036/5039/5042/5124/5153, JXI5020, TLC59283 ,

ICN2053BP/2083S or other types you require.

4. Famous power supply selection: Meanwell, E-energy, Greatwall etc., CE, UL certified.

5. Famous control system for optional: Synchronous: Nova, LINSN, Mooncell etc.;

Aynchronous: Tianyi, Xixun or Betters etc.. They are stable, wide application, easy to operate,

good refresh rate and grey scale, powerful functions to support your need.

6. Skillful and strict assembly workmanship, can assure you high quality guaranteed products.

7. All our products support 3 years warranty or more according to your requirements.

8. Immediate, patient and considerated service is our principle.

9. All products are CE, RoHS, FCC, TUV certified.









Product Detail

Customized Flexible Led Indoor Display 3840hz HD P3.91 Full Color 1200cd/㎡ Brightness 0









Specifications



Model No. P2.604 P2.98 P3.91 P4.81
Pixel pitch 2.604mm 2.98mm 3.91mm 4.81mm
Led lamp 1515 2121 SMD2121 SMD2121
Pixel density 147456 pixel/sqm 112896 pixel/sqm 65410 pixel/sqm 43222 pixel/sqm
Brightness 1300cd/sqm 1000cd/sqm 1500cd/sqm 1300cd/sqm
Drive mode 1/32 scan 1/28 scan 1/16 scan 1/13 scan
Panel dimension(W*H*D) 500x500x75mm/19.7" x 19.7" x 3"
Panel resolution 192x192 pixel 84x84 pixel 128x128 pixel 104x104 pixel
Panel weight 7.2KG 7.2KG 7.2KG 7.2KG
Cabinet material Die casting aluminum
Max power consumption 800w/sqm 800w/sqm 800w/sqm 850w/sqm
Average power consumption 325w/sqm 325w/sqm 325w/sqm 350w/sqm
Viewing angle H:120° V:120°
Refresh rate 3840Hz
Gray scale 14-16 bit
IP rating IP43
Operating temperature -20℃~+60℃
Lifetime 100000 hours








Special Performance



Customized Flexible Led Indoor Display 3840hz HD P3.91 Full Color 1200cd/㎡ Brightness 1









Accessories

Customized Flexible Led Indoor Display 3840hz HD P3.91 Full Color 1200cd/㎡ Brightness 2









Advantage



Ultra-light---lighter 40% than aluminum die-csting cabinet

Super slim---high-strength,more slim than aluminum in the design,thiner around 30%

Fast cooling---wxcellent heat dissipation perormance to protet the modular circuit

Anti-interference---special anti electromagnetic interference function

High strength---support the weight of 300kg through tension test,more strength than aluminum

Easy installation---installed by quick lock for 20s only

High precision---seamless splicing though CNC machining

High universality---can be processed according to module drawing,used for outdoor and indoor

Easy maintenance---can be maintained form front side

High cost-effective---large-scale production,complete production & supply chain









Our Service



1. Warranty
1) We provide warranty of all components for 3 full years. During this time, we will replace or repair our goods for free if there is something wrong with them.
2) We will provide maintenance for a lifetime and charge for the raw materials only.

2. Technology Training
1) We provide the technology training for free, which contains the operation training and maintenance
2) training in the factory.
3) We will send our engineers to your country by negotiation.

3. Maintenance and Consultation
1) We provide full maintenance for a lifetime and charge for the raw materials only.
2) We also provide lifetime consultation by E-mail, Skype, WhatsApp or other ways for free.

4. Documents and Certification
1) We provide the operation manual, software, test report and so on.
2) We can also provide all kinds of certification such as CE, LVD, RoHS and so on.

5. CAD Drawing and Fixing
1) We provide CAD drawing on how to fix up the display for free and some other expert suggestion.
2) We will send our engineers to your place if we are expected after our negotiation.

6. Additional Service
1) We provide you the forwarding information, and some other information such as flight box, structure
