Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof Waterproof

Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof Waterproof

    • Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof  Waterproof
    • Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof  Waterproof
    • Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof  Waterproof
    • Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof  Waterproof
  • Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof  Waterproof

    Product Details:

    Place of Origin: China
    Brand Name: SCXK
    Certification: CE/ROHS/FCC/ISO/UL
    Model Number: SMD P4

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: negotiation
    Packaging Details: flight case, wooden case, carton, it is up to you.
    Delivery Time: 7-10 working days after receive your payment
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 5000sqm per month
    Contact Now
    Detailed Product Description
    Product Name: Wifi Curve SMD P4 LED Screen 62500 Pixel 16 Scanning , Dustproof Waterproof Pixel Density/pixels/m²: 62500
    Pixel Configuration: RGB 3 In 1 Color Uniformity(chromaticity Coordinate): ±0.003
    Package: Flight Cases Or Wooden Cases Vertical View Angle: 120(degrees)
    High Light:

    led display smd

    ,

    smd led display

    Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof Waterproof



    Advantages



    1. The module uses flexible material circuit board, whole screen bending angle size arbitrary customization

    2.Costing saving for installation and maintenance:Fast locks design, cabinets can be easily assembled in 7 seconds. Dual-maintenance, no need fan, noiseless, low power consumption.vertical / Horizontal viewing angle 160 degree. Calibration for high quality picture.

    3. High contrast and high image quality:High quality led lamp with black body structure and black lamp mask to provide 3000:1 contrast and clearer and more bright-colored image.

    4. Customized playback content:Play content can be customized: 360 view display Video + photo + text + any language



    Product description



    This kind of product is special for indoor or outdoor column facade, can be cylinder and square shape. 360 degree viewing angle show a perfect viewing experience.



    Front service makes it easy to maintain if there is any problem. City development and improvement need this kind screen better.



    Free Training

    Via internet, or in our workshop, we provide all the training including process of operation, installation, maintenance, system set up, etc



    ♦ Product specification

    indoor  SMD P4
    Lamp size 2020
    Resolution/mm 4
    Pixel configuration RGB  3 in 1
    Pixel density/pixels/m² 62500/m²
    Module resolution 32x32
    Module size/mm 128x128
    View distance ≥4m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >1800cd/㎡
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 120(degrees)
    Signal Process bit 10 or 14 bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:5km
    Driving mode Constant driving current
    Scanning mode 1/16
    Frame rate 60Hz
    Refresh frequency >1200Hz
    Control mode Computer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted

    255 steps. No grey loss

    Out of control point <1/10000
    Working hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃ Storing temperature range: -30-65℃
    Maximum power:/㎡ <1100W
    Average power:/㎡ <280W
    Self-check technology

    LED spot self-check, communications check, power check,

    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,

    send out warning signs to the operators.(need customization)

    Software environment WindowsNT,Windows1999,WindowsXP
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast  (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%



    ♦ Production process:

    1) Incoming Inspection→2) SMD→3) Plug-in

    →4) Wave Soldering→5) After Welding→6) Testing

    →7) Semi Finished Aging→8) Module Assembly

    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing



    ♦ Packaging and shipping

    Wooden case or flight case package are available.

    Shipping by sea,air or DHL,multiple shipping ways for your choice.



    ♦ Why choose us:

    Continues Quality

    With more than 10 years experience in led display producing,equipments are updated regularly.What’s

    more,unique standardized and module production ensure our products continuous quality.



    Competitive Price

    With large scale production capacity and professional production technology,our company have built

    effective modular production.We always stick to promote the technical innovation and reduce cost to

    benefit customers.



    Fast Delivery

    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

    inventory will be used to maintain your uninterrupted supply of the products.



    Perfect Service

    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

    you.

    After-sales:We will track the products usage and then constantly perfect our products.



    ♦ Our project
    Wifi Curve SMD p4 LED Screen 62500 pixel 16 scanning , Dustproof  Waterproof 0
