| Place of Origin: | China |
| Brand Name: | SCXK-oled |
| Certification: | CE/ROHS/FCC/SGS |
| Model Number: | P2.5 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in wooden case and flight case for outer packing |
| Delivery Time: | 10 working days after received your payment |
| Payment Terms: | T/T or western Union |
| Supply Ability: | 5,000/ Sq m per month |
| Product Name: | Indoor P2.5 Led Display | Module Size(W * H): | 160mm*160mm |
|---|---|---|---|
| Standard: | CE/ROHS/FCC/ISO2001 | Tube Chip Color: | Full Color |
| Pixel Pitch: | 2.5mm | Module Qty: | 1pcs |
| Type: | Free Standing | Resolution(W*H): | 64dots*64dots |
| High Light: | indoor led display screen,indoor led billboard |
||
Shenzhen Shichuangxinke Electronic Co.,Ltd set up in 2005,it has been devoting to high-quality LED display designing & manufacturing for 12 years. equipped with professional team and modern facilities, we manufacture fine LED display products, wide application in airports, stations,ports,gymnasiums, banks, schools, churches ,etc.our LED products are deployed across 100 countries all over the world,covering America, Europe and Africa. Asia, Middle East,
specification:
SMD indoor full color LED video display indoor stage LED display P4
* Die-casting aluminum /extrusion aluminum secure and nice in constitution.
* No fans, mute when operation.
* Dustproof, IP43.
* High refresh rate and high gray depth.
* Completely black LED with high contrast.
* Standard cabinet size is 500mm x 500mm and 480x480mm.
* Large viewing angle, the panel viewing angle is up to 140, the vertical angle could reach 140, the image won't be out of shape and color cast between the rang.
* Exactly connected and easy to install and dismount.
| Pitch | 2.5mm | 3mm | 3.91mm | 4.81mm | 5mm | 6mm | 6mm | 6.25mm | 8mm |
| Density(dot/sqm) | 160000 | 111111 | 65536 | 43403 | 40000 | 27777 | 27777 | 25600 | 15625 |
| LED Encapsulation | SMD3in1 | SMD3in1 | SMD3in1 | SMD3in1 | SMD3in1 | SMD3in1 | SMD3in1 | SMD3in1 | SMD3in1 |
| Module Size(mm) | 160*160 | 240*240 | 250*250 | 250*250 | 240*240 | 240*240 | 288*288 | 250*250 | 240*240 |
| Module Resolution(pixel) | 64*64 | 80*80 | 64*64 | 50*50 | 48*48 | 40*40 | 48*48 | 40*40 | 30*30 |
| Cabinet Size(mm) | 480*480 | 480*480 | 500*500 | 500*500 | 480*480 | 480*480 | 576*576 | 500*500 | 480*480 |
| Cabinet Resolution(pixel) | 192*192 | 160*160 | 128*128 | 100*100 | 96*96 | 80*80 | 96*96 | 80*80 | 60*60 |
| Cabinet Weight(kg) | 8 | 8 | 9.5 | 9.5 | 8 | 8 | 10.5 | 9.5 | 8 |
| Max Power Consumption(w/sqm) | 800 | 750 | 700 | 600 | 500 | 650 | 700 | 650 | 600 |
| Ave Power Consumption(w/sqm) | 400 | 350 | 300 | 250 | 200 | 320 | 350 | 320 | 300 |
| Brightness(cd/sqm) | 1200 | 1500 | 1200 | 1500 | 1500 | 1500 | 2000 | 1800 | 2000 |
| Gray Scan | >4096 | >4096 | >4096 | >4096 | >4096 | >4096 | >4096 | >4096 | >4096 |
| Refreshrate(Hz) | 600-4800 | 600-4800 | 600-4800 | 600-4800 | 600-4800 | 600-4800 | 600-4800 | 600-4800 | 600-4800 |
| Best Viewing Distance(m) | 2-100 | 3-100 | 4-100 | 5-100 | 5-120 | 6-150 | 6-150 | 6-150 | 8-150 |
| Drive Mode | Constant Current Drive | ||||||||
| Viewing Angle | Horizontal:140° Vertical:140° | ||||||||
| Protection Level | IP43 | ||||||||
| Working Temperature | -20°C-50°C | ||||||||
| Working Humidity | 10%-60% | ||||||||
| Working Voltage | AC 110V~220V±10% | ||||||||
| Refresh Frame Frequency(Hz) | 60 | ||||||||
| Lifespan | 100000hours | ||||||||
| Malfunction Dot Rate | <0.0002 | ||||||||
| Control system | LINSN/ZDEC/DBSTAR/NOVA/COLORLIGHT | ||||||||
Payment and delivery
1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ FAQ
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
