Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P16 |
| Minimum Order Quantity: | 3 square meters |
|---|---|
| Price: | USD 550-750 square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | 16mm | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | Static Full Color | Module Size: | 256x256mm |
| Cabinet Size: | 1024x1024mm | Application: | Stadium,airport,shopping Mall,street Advertising |
| LED: | DIP | Warranty: | 2 Years |
| Highlight: | outdoor advertising led display,advertising led billboard |
||
DIP346 LED Display P16 Screen for Outdoor Rental replace LED TV screen
Description:
Adopting real pixels, displaying true color outdoor, static constant current driving method
High brightness, high refresh rate, low power consumption
Long service life, low runaway rate
3 years warranty, provide free operation training
DIP LED package ensures high brightness even under sunlight, anti-corrosion, anti-fogging, good waterproof performance,
Waterproof rating IP65
Brightness can be adjusted automatically according to different environments,
The screen can be set to turn on and off automatically when it is fixed.
Can be fixed on the wall, street, top of the building, also can be hung for rent, meet the requirements of live broadcast, live meeting, banquet, party, etc., to display the content you want in the form of video, graphic, animation, etc., can be connected with PC computer or network, also can be controlled remotely through the asynchronous system.
Specifications :
| outdoor DIP P16 | |||||
| Resolution/mm | 16 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 3906pixel/m² | ||||
| Module resolution | 16x16 | ||||
| Module size/mm | 256x256MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Product Advantages:
1). Wide application field :
Outdoor Commercial advertising LED display screen, LED display screen for shopping mall,Stadium perimeter LED display ,bank&stock exchange LED display for rates showing,train & bus station LED display screen .
2). High brightness:
Automatic or manual adjustment of the brightness of the display.
3).Top LED chip:
Supplied by Epistar of china & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display system.
4). Clear vivid image quality:
Throughout the show, the picture clear, bright color.
5).Installation is simple,easy to use:
Easy and simple installation interface and user friendly software to ensure that customers use easily.
6).The list of available Models of our outdoor LED display screen:
Outdoor:P10,P12,P16,P20,P25.
Factory advantage:
1. Product diversification:
Outdoor/indoor LED display screen models are diversified, and the box can be customized to meet a variety of needs and win more profits for customers.
2. Experienced and professional:
10 years experience in LED display production, professional craftsmanship and design.
3. Best raw materials:
High quality, high brightness, long life.
4. Competitive price:
100% factory price, reasonable and competitive price.
5. Strict quality control:
100% inspection before packing, ensure the quality before shipment.
6. Quality Assurance:
The service life of LED display is more than 100,000 hours.
All of our LED displays have passed CE, FCC, RoHS certificates.
7. Timely and professional service:
We will respond to any of your inquiries within 24 hours on working days and provide you with useful suggestions.
Please feel free to contact us if you have any questions or problems. Thank you!
Welcome to visit our website and inquire us more info,waiting for you all the time!!!
Contact Person: Lillian seori
Tel: +8619386814677
