Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China |
| Brand Name: | SCXK |
| Certification: | CE/ROHS/FCC/SGS/ul |
| Model Number: | 6 |
| Minimum Order Quantity: | negotiation |
|---|---|
| Price: | negotiation |
| Packaging Details: | Packed in wooden case and flight case for outer packing |
| Delivery Time: | 10-15 working days after received your payment |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5,000/ Sq m per month |
| Product Name: | Outdoor P6 Advertising Billboard | Module Size: | 192mm*192mm |
|---|---|---|---|
| Module Resolution: | 32dots*32dots | Cabinet Size: | 960mm*960mm |
| Cabinet Resolution: | 160*160 | Display Color: | Full Color |
| Led Chip: | Epistar | ||
| High Light: | full color led signs outdoor,outdoor full color led screen |
||
Shenzhen Shichuangxinke leads the way in LED display manufacturing & technology. Its outdoor & indoor commercial advertising LED display, rental use LED display, fixed installation LED display, sports stadium perimeter LED display, mobile trailer LED display, water floating LED display, transparent LED curtain display, digital LED billboard, LED components & complete LED full color video systems undergo stringent quality control at ISO 9001-certified manufacturing plants.
We offer users friendly products that optimize productivity and business efficiency and maintain the highest standards of design and quality. Customer satisfaction is our prime objective and our high quality LED video display screen used in more than 140 countries and win a high reputation.
Designed with utmost precision and advanced technologies, the new series of our Outdoor Full Color Stadium Perimeter Screen finds its extensive usage in sporting events, exhibitions and allied.Sourced from some of the distinguished manufacturers of the industry, the range available with us comes in following
Spec
| Model | Unit | P6 |
| Pixel pitch | mm | 6 |
| Pixel resolution | pixel/m² | 27778 |
| Pixel configuration | - | DIP346 1R1G1B Oval LED lamp |
| Viewing angles | horizontal | 110° at 50% brightness |
| Weight | kg/m² | 52 |
| Brightness | CD/m² | 6000 |
| Contrast ratio | - | 3,000:1 |
| Color temperature | K | 6,500 |
| Color processing | bit/color | 12 |
| Colors | number | 1.07 billion |
| Grayscale | steps | 1024level |
| Best viewing distance | m | 6 -100 |
| Refresh rate | Hz | ≥1,000 |
| Control system | - | LINSN |
| Life time | h | 75,000 to 50% brightness down |
| Power consumption | W/m² | 800 |
| (maximum/average) | W/cabinet | 280 |
| Working voltage | - | AC220V or AC110V / 50-60 Hz |
| Cabinet dimension | mm | customised |
| Cabinet material | - | cold rolled steel |
| Protection rate | IP | front: IP65, back: IP55 |
| Working temperature | °C | -20 to +55 |
| Working humidity | RH | 10 to 90% |
| Image source with LED video processor | - |
HDMI, CVBS, YC, YUV, RGB DVI, SDI/HDSDI |
| Image source without video processor | - | DVI |
| Maximum transmitting distance |
m m |
<100 with network cable <2,000 with optical fiber cable |
| Cabinet interfaces | - | 2 signal ports, 2 power ports |
| Maximum per power entry | cabinets |
220V power input: 6 110V power input: 3 |
| Maintenance | - | back |
The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available
The wire or wireless controll system are available .( 3g and wifi controll will be welcome)
Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipment.
Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6, Small order accepted.
Package
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
Thank you very much for viewing our website, and wish you a nice day!
