Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P2 |
| Minimum Order Quantity: | 1 square meters |
|---|---|
| Price: | USD 3000-3500 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 5000sqm per month |
| Pixel Pitch: | 2 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Scanning Mode: | 1/32 Scanning | Module Size: | 128x128mm |
| Cabinet Size: | 512x512mm | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | Material: | Aluminum |
| Warranty: | 2-3 Years | IC: | MB5124/MB5024 |
| Highlight: | led full color screen,indoor led billboard |
||
Free maintenance 2 years warranty P2 indoor LED Display screen
Advantages:
1.Leading technology of high grey level and low brightness, contrast ratio 3000:1, processing depth 16bit, refresh rate 2800Hz
2.Wide color range, excellent color uniformity, no rainbow effect, broadcasting strong stability
3.Seamless, bezel-free, size-free splicing with adjusting accuracy is 0.01mm
4.Metal cooling structure, no noise and no fan
5.Die-casting aluminum design, CNC precise processing
6.Modular front maintenance, supporting hot plugging for unit module and wires
Product Description
CE, FCC, RoHS and C-Tick certified.
All parts have a 2-year warranty.
High-definition refresh, seamless splicing, good uniformity, high-definition video, lifelike picture.
SMD LED package, wide viewing angle, horizontal and vertical viewing angles are more than 120 degrees, no flicker and color cast, excellent visual effect.
Lightweight and slim, easy to move and carry.
The picture is lifelike and clear, the noise is very low, equipped with advanced testing equipment, supports any PC operating system, and can play video, text, Flash, music, clock, chart and other information.
Front-end maintenance with magnetic module is convenient and fast.
Specifications :
| outdoor DIP P2 | |||||
| Resolution/mm | 2 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 250000/m² | ||||
| Module resolution | 64x64 | ||||
| Module size/mm | 128x128mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/32 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Our Service
1. Well-trained and experienced staffs to answer all your enquires in fluent English.
2. Protection of your sales area, ideas of design and all your private information.
3. Your inquiry related to our products or prices will be replied in 24hrs.
4. Distributorship are offered for your unique design and some our current models.
5. The unit price depends on the quantity, we can offer you at a competitive price.
FAQ:
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
1. We have the advantage of a full range of LED display production
2: Goods supply from indoor and outdoor P10, P8, P6, P4,P3,P3.91, P4.81, P2, P2.5, P1.976 have sufficient inventory, at the same time has high quality, let you buy at ease, use at ease
3. We have round-the-clock online customers to help customers and give customers product performance introduction, as
wellasproduct advantage analysis; According to the actual situation and the use of the situation, for the customer
evaluation,choosethe most reasonable scheme
4: At the same time, we can provide customers with professional training on the operation and maintenance of the led display
system Display troubleshooting
