Shenzhen Shichuangxinke Electronics Co.,Ltd
professional makes good quality, provide perfect product and service for every customer.
 |
| Place of Origin: | China ,Guang Dong |
| Brand Name: | Shichuangxinke |
| Certification: | CE RoHS FCC CCC TUV UL |
| Model Number: | SCXK-P4 |
| Minimum Order Quantity: | 3 square meters |
|---|---|
| Price: | USD1900-2100 per square meters |
| Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
| Delivery Time: | 7-10 working days after deposit payment received |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 5000sqm per month |
| Resolution/mm: | 4 | Pixel Configuration: | 1R1G1B |
|---|---|---|---|
| Module Size: | 256x128MM | Cabinet Size: | 512x512MM |
| Scanning Mode: | 1/8 Scanning | Material: | Aluminum |
| Warranty: | 3-5 Years | Certificates: | CE RoHS FCC CCC UL |
| Application: | Stadium,airport,shopping Mall,street Advertising | ||
| Highlight: | smd led display,outdoor smd led display |
||
Indoor Fixed Installation LED Video Wall P2.5 P3 P4 P5 P6 Indoor LED display Screen
Outstanding Performance & Quality:
Supported by advanced technology and a team of professionals, SCX presents world-class standard LED displays with beautiful images, long-lasting stability, low power consumption, wide viewing angles, and high levels of protection.... Fully automated production to control our high quality, best color . Consistency for better performance.
-Energy saving, low power consumption, long life of 100,000 hours (about 10 years).
-SCX guarantees that the products we provide are new, complete and unused.
-Unique ventilated fan design with high heat dissipation capacity and waterproof.
-SCX performs quality control on every process from material - production - testing - packaging - delivery.
Frank and honest:
SCX sales-team promise to be frank and honest in a proffessional way on how to choose the most suitable products according to the installation site. Also respect your requirements and offer the most suitable solution accordingly.
Specifications :
| Outdoor P4 LED advertising Display Screen | ||
| Information | Pixel Pitch | 4mm |
| Pixel Density | 62500 Pixels/m2 | |
| Pixel Configuration | 1R1G1B | |
| LED Wavelength | Red: 615 nm - 635 nm | |
| Green: 520 nm - 535 nm | ||
| Blue: 465 nm - 475 nm | ||
| LED Module | Module Size(mm) | 256(Width) × 128 (Height) |
| Module Resolution | 64(Width) × 32 (Height) | |
| Cabinet | Cabinet Size(mm) | 512 (Width) ×512(Height) |
| Cabinet Resolution | 128 (Width) × 128 (Height) | |
| Total QYT Module Per Cabinet | 4 (Width) ×4(Height) | |
| Cabinet Weight | 30kg/m2 | |
| Cabinet Material | Die-casting Aluminum LED Display | |
| Power | Input Voltage | 100-240V AC, 50/60Hz |
| Max Power Consumption | 1200 Watt/m2 | |
| Avg. Power Consumption | 720 Watt/m2 | |
| Brightness | ≥1800cd/m2 | |
| Brightness Uniformity | Luminance Discrepancy < 5% | |
| Best Viewing Angle | Horizontal:140°,Vertical:70° | |
| Viewing Distance | 5 - 15 meters | |
| Ambint Conditions | Temperature Range | Working:-20deg. to +60deg |
| Operating Humidity | 10%90%RH | |
| Ingression Protection Grade | IP40 | |
| Processing | Scanning Mode | 1/8 scanning |
| Signal Input | DVI, Composite Video for Live Video | |
| Supported Networking | Through LAN/WAN, RS 232/RS485 | |
| Controller | Linsn or Nova | |
Pre-sales service:
Email,telephone call or social network online timely communication, provide suggestions & solutions according to customer's requirements.
After-sales service:
-Keeps you informed of the status of your LED display's production process.
-Take photos and videos of your LED displays for reference after production is complete.
-Arrange shipment and provide tracking service until the product arrives smoothly.
-Provide all the documents in time, such as bill of lading, packing list, commercial
etc. to help customers clear customs and pick up the LED displays.
-Guidance service: If customers encounter problems in the process of installation and use, we support online remote video training and guidance.
-Provide installation structure drawing to help customers build the structure, if customers need, we can arrange engineers to your country to guide and assist in the installation of LED display, but customers need to bear the relevant costs.
-We can provide 24/7 technical support through online remote control as long as customers need.
-Free technical training, such as teaching customers how to operate the software, how to check faults and maintain the LED display.
-Warranty period: 2 years after the standard product is shipped from the factory, and the warranty period can be extended according to the special needs of customers. We are committed to free repair or replacement within the warranty period, lifelong maintenance.
-Maintenance terms: timely response, as soon as possible to solve the problem, to ensure good use. During the warranty period, all maintenance costs are exempted. Under normal use and storage, our company will be responsible for the equipment. If product quality failure occurs, our company will repair and replace the parts for free. After the expiration of the maintenance period, only the material cost will be charged. Lifetime maintenance
RFQ:
|
Q1: What's the warranty of your LED Display Screen ? A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps. |
|
Q2: What about your pre-sale service and post-sale service? A2: For pre-sale service: We have a professional sales team and 13 years technical team who are willing to answer your question 24/7. We can offer a whole complete solution for your project! |
|
Q3: Whats your payment term? How long it takes to delivery? A3: We accept T/T and L/C, For both T/T and L/C, At least 30% deposit in advance, and the rest 70% before delivery. |
|
Q4: What's the control system? A4: For synchronization control: We use Nova, Linsn Or Colorlight control system. |
|
Q5: How can you ensure the led display product quality? A5: Our led display screen quality is our core competence, for 8 years, what we rely on. |
Welcome to visit our website and inquire us more info,waiting for you all the time!!!
Contact Person: Lillian seori
Tel: +8619386814677
