Place of Origin: | China ,Guang Dong |
Brand Name: | Shichuangxinke |
Certification: | CE RoHS FCC CCC TUV UL |
Model Number: | SCXK-P6 |
Minimum Order Quantity: | 1 square meters |
---|---|
Price: | USD600 square meters |
Packaging Details: | wooden box flight case, wooden case, carton, it is up to you. |
Delivery Time: | 7-10 working days after deposit payment received |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 5000sqm per month |
Resolution/mm: | 6 | Pixel Configuration: | 1R1G1B |
---|---|---|---|
Scanning Mode: | 1/8 Scanning | Module Size: | 192x192 |
Cabinet Size: | 960x768mm/576x576mm | Certificates: | CE RoHS FCC CCC UL |
Application: | Stadium,airport,shopping Mall,street Advertising,stage Background | Material: | Aluminum |
Warranty: | 3-5 Years | ||
High Light: | advertising led display board,outdoor advertising led display |
Features:
1. Durable fresh color and high brightness by adopting high quality LEDs.
2. Energy saving 24% by using high efficiency IC driver and improved PCB design.
3. Persistent Uniformity, contrast and flatness of outdoor LED screen, increasing the profit and competitiveness of the operator.
4. Anti-UV module mask, Anti-Oxidation module frame with protection from deformation.
5. Aircraft-grade connectors of the power, signal to ensure stable connection and high reliability.
6. IP65 protection grade, durable nature to enable the outdoor LED screen working in all weather outdoor environments.
1) Corrugated Carton Package-- Economic option for fixed installation.
2) Plywood case--Fix installation--5-9 panels per case as customized
3) Flight case-- Rental Purpose--5-9 panels per case as customized
Specifications :
outdoor SMD P6 | |||||
Resolution/mm | 6 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 43222m² | ||||
Module resolution | 27778 | ||||
Module size/mm | 192x192mm | ||||
View distance | 14-300m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | >7500cd/㎡ | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/13 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | >3000Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
Our service1. Your inquiry related to our products or price will be replied in 24hrs2. OEM&ODM, any your customized lightings we can help you to design and put into product3. Distributoership are offered for your unique design and some our current models4. Protection of your sales area, ideas of design and all your private information5. Top quality+Reasonable price+Responsible After Service=Successful & Win
Trade Terms1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 40% deposits before production, 60% balance to be paid before delivery 3. Shipping freight are quoted under your requests4. Shipping port: Shenzhen, Mainland China5. Warranty time: 2-3years
6. Delivery time: 3-12working days
We are a Chinese LED display screen manufacturer.Some of our primary products are sports stadium LED display,square LED screen,giant LED video wall,airport LED display panel,advertising LED billboard,Mobile led rental display,Stage LED display board,wall large LED display,exhibitions,shopping malls,and more.As a result,our outdoor and indoor LED display are favored by customers in many countries,
such as : UK,Italy,Germany,USA,Spain,Singapore,Brazil,and so on.Please contact us for more detailes information on our LED display screens,we can meet the international demand for our high quality indoor led display,outdoor led display,rental led display,and creative led display.We look forward to hearing from you!
