P6 outdoor led advertising screen waterproof big screen outdoor led tv

P6 outdoor led advertising screen waterproof big screen outdoor led tv

  • P6 outdoor led advertising screen waterproof big screen outdoor led tv
  • P6 outdoor led advertising screen waterproof big screen outdoor led tv
  • P6 outdoor led advertising screen waterproof big screen outdoor led tv
P6 outdoor led advertising screen waterproof big screen outdoor led tv
Product Details:
Place of Origin: CHINA
Brand Name: SCXK
Certification: CE/ROHS/FCC/ISO/UL
Model Number: P6
Payment & Shipping Terms:
Minimum Order Quantity: 1 SQM
Price: negotiation
Packaging Details: flight case, wooden case, carton, you choose what you like。
Delivery Time: 7-10 days
Payment Terms: T/T, Western Union, MoneyGram, L/C, D/A
Supply Ability: 5000 sqm per month
Contact Now
Detailed Product Description
Pitch Pixel: 6mm LED Pixel Density: 27778pixel/m²
Pixel Configuration: 1R1G1B Pixel: 32*32dots
Module Size: 192*192mm Driving Mode: 1/8 Scan
Cabinet Size: 576*576mm Warranty: 3 Year
Highlight:

led display rgb

,

full color outdoor led display

P6 outdoor led advertising screen waterproof big screen outdoor led tv





Product Description

1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.



Applications

--- Outdoor and indoor advertising, digital billboards, advertising companies
--- Sports halls, fields, playgrounds,school church
--- Airports, bus stations and railway passenger terminals.
--- Facades of shopping malls, department stores, banks and car dealerships.
--- Architecture and social projects, information systems in cities.
--- Show-business, concerts, festivals, motor shows and other public events.


Module Parameter

Pixel pitch 6mm
Pixel configuration 1R1G1B
LED type 3-in-1 SMD 2727
Module size 192x192mm
LED lamp KingLight or Nationstar
Module resolution 32x32dots


Cabinet Parameter

Cabinet size 960x960mm
Cabinet material ironed steel cabinet
Cabinet weight 32kg
Ingress protection Front/Rear IP65/IP54


Whole Screen Parameter

Pixel density 27778 dots/m²
Brightness ≥6000 cd/m²
Viewing angle H≥120° V≥120°
Min.viewing distance 6m
Max.power consumption 850W/m²
Avg.power consumption 350 W/m²
Working voltage 110~220VAC±15%
Interface HUB75
Colors 16.7millon colors
Gray level 65536
Refresh rate ≥1920Hz
MTBF ≥100,000 hours
Lifespan ≥500,000 hours
Protective function Over-heat/Over-load /Power-down /Power-leakage
/Lightning-protection etc.
Operating temperature -10℃ ~ +60℃
Storage temperature -20℃ ~ +60℃


Control System Parameter

Video signal (with video processor) AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature Adjustable by software
Brightness level 256 levels, automatic adjustment by software
Control way Computer, video-synchronous, real-time, off-line, wireless, internet etc.


Cabinet

P6 outdoor led advertising screen waterproof big screen outdoor led tv 0

P6 outdoor led advertising screen waterproof big screen outdoor led tv 1



Why choose us

Continues Quality

With more than 10 years experience in led display,equipments are updated regularly.What’s more,unique standardized and module production ensure our products continuous quality.



Competitive Price

With large scale production capacity and professional production technology,our company have built effective modular production.We always stick to promote the technical innovation and reduce cost to benefit customers.



Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products.



Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to you.

After-sales:We will track the products usage and then constantly perfect our products.




Company profile
Shenzhen SCXK Electronic Co.,Ltd established in 2009 and has the standard new factory, about 100 employees. We have outstanding R&D department and after-sell service workers, and separately design ability. Our product mainly included led indoor full color display, led outdoor full color display,led indoor full color display, led wireless car usd screen, poster screen,transparent screen etc.It can be used on the shopping mall, bank, bus station, train station, center of downtown, airport,school,factory,bus,taxi and so on. We adapt many methods and very good after-sell service to sell our product all over the world. Whenever and wherever we are, we always take the principle that is: professional makes good quality,good price product market to price product market to provide perfect product and service for our customers.
P6 outdoor led advertising screen waterproof big screen outdoor led tv 2
Certificate
P6 outdoor led advertising screen waterproof big screen outdoor led tv 3


Packaging and shipping
Packing:1.wooden case packing for ironed steel cabinet.
2.flight case packing for die casting aluminum cabinet.
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.
