P2.5 HD Full Color Video Display stage background led display

Name: P2.5 HD Full Color Video Display stage background led display
Brand: Shenzhen ShiXin Display Technology Co.,Ltd
SKU: P2.5
Price: 10000 USD
Availability: InStock

Brand Name:	SCXK
Model Number:	P2.5
MOQ:	negotiation
Price:	negotiation
Payment Terms:	T/T or western Union
Supply Ability:	5000sqm per month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE/ROHS/FCC/ISO/UL

Product Name:

P2.5 Led Display

Module Size(W * H):

160mm*160mm

Standard:

CE/ROHS/FCC/ISO2001

Led Chip:

Epistar

Pixel Pitch:

2.5mm

Resolution(W*H):

64dots*64dots

Packaging Details:

flight case, wooden case, carton, it is up to you.

Highlight:

led stage display

stage background led screen

Product Description

P2.5 HD Full Color Video Display stage background led display

Company operating philosophy is: People oriented, leading technology, quality first, integrity service.

Shichuangxinke Electronics is a led display and peripheral products R & D, production, sales and service in one of the high-tech enterprises in Shenzhen.started in 2005,we have gained aboundant experience in led display industry. we own a huge LED industry base, with advanced management mode, strong R & D capability and abundant raw material resources, to create high quality products. And according to the market demand, has formed a complete system of products.

SCXK electronic would like to coexist with peers from all walks of life hand in hand and seek common development, innovate constantly, to provide better and more perfect service for the majority of new and old customers.

Product Description

Model	High definition P2.5 160mm*160mm die casting LED screen
Pixel pitch	2.5mm
Pixel density	160000 dots /sqm
Module size(W*H)	160mm(width)*160 mm(height)
Module pixels(W*H)	64 dots *64 dots
Pixel configuration	1Red 1Green 1Blue
Drive mode	constant current driving 1/32 scan
LED lamp type	SMD2121
Cabinet size(WHD)	480mm * 480mm
Net weight	6.5 Kg / cabinet
Cabinet resolution	192 * 192 dots
Color scale	65,536 degree
View angle(H/V)	140 / 120 degree
Brightness (White balance)	about 1300 -1800cd / sqm.
Power consumption(one cabinet)	Max : 300 Watte / cabinet , Average : 120 Watte / cabinet
Operating temperature	- 30 °C----+ 60 °C
Operating humidity	10% - 95% RH
Life time	≥100,000hours
MTBF	5,000 hours
Whole Display Flatness	≤0.5mm Juncture
Frame frequency	25-60 Hz/s
Refresh rate	≥2000Hz /s
Control distance	100m (without repeater) , single mode fiber : 20km, multi mode fiber: 500m
Inputting voltage	90-264VAC 47--63Hz
LED control system	LINSN , Nova-sta rs selectable
Operating system	Windows Xp / Windows 7 / windows 8 /8.1 / windows 10
Protection grade	IP31
Maintenance way	Rear Access
Accepting signal with video processor	PAL / NTSC / SECAM , S-Video ; VGA ;RGB ; Composite Video ; SDI
