Outdoor RGB LED Full Color custom Display Flexible Module P4 High Resolution For Advertising

Outdoor RGB LED Full Color custom Display Flexible Module P4 High Resolution For Advertising

    • Outdoor RGB LED Full Color custom Display Flexible Module P4 High Resolution For Advertising
    • Outdoor RGB LED Full Color custom Display Flexible Module P4 High Resolution For Advertising
  • Outdoor RGB LED Full Color custom Display Flexible Module P4 High Resolution For Advertising

    Product Details:

    Place of Origin: China(Mainland)
    Brand Name: SCX
    Certification: CE,ISO,SAA,UL
    Model Number: SCX-P4

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 square metres
    Price: 900-1000 USD/sqm
    Packaging Details: Wooden and flight cases,it's up to you.
    Delivery Time: 12-15 working days after receiving down payment.
    Payment Terms: T/T, Western Union
    Supply Ability: 5000 sqms/month
    Contact Now
    Detailed Product Description
    Brand: SCX Module Size: 256*128mm
    Color: Full Color Cabinet Size: 512*512mm
    Resolution: 64*32 Scan Mode: 1/8
    Application Places: Shopping Mall,Stations,Airports,Commercial Centure... Type Of Cabinet: Die-cast Aluminum/Iron Cabinet
    High Light:

    rgb led screen

    ,

    full color outdoor led display


    Outdoor RGB LED Display flexible module P4 for Advertising High Resolution

    Short introduction about our company
    1)Manufacturer with over 11 years experience in electronic goods & PCB assembly.
    2)over 400 employees.
    3)6 high-speed Panasonic SMT machine, 6 Yamaha SMT machine, 2 AOI testing equipment, etc.
    4)10 production lines.
    5)6S management.
    6)Passed ISO9001:2008 & ISO14001:2004 and CE/RoHS/FCC certified.


    outdoor P4 LED screen Display
    Resolution/mm 4
    Pixel configuration 1R1G1B
    Pixel density/pixels/m² 62500 pixels/sqm
    Module resolution 64*32mm
    Module size/mm 256*128mm
    View distance 4-300m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >7500cd/square meter
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 60(degrees)
    Signal Process bit 10 or 16bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
    Scanning mode 1/8 scanning
    Fresh rate 60Hz
    Refresh frequency >3000Hz
    Control mode

    Asynchronous,3G,4G,Wifi

    Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
    255 steps. No grey loss
    Out of control point <1/10000
    Aging hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃
    Self-check technology LED spot self-check, communications check, power check,
    temperature monitor(need customization)
    Remote monitoring Remote supervision and control, record potential fault,
    send out warning signs to the operators.(need customization)
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%


    Main features of the products:

    1)Wide application field : Outdoor Commercial advertising LED display screen, LED display board for shopping mall,Stadium perimeter LED display ,bank&stock exchange LED display screen for rates showing,train & bus station LED display screen .
    2)High brightness:7500cd/m2 Automatic or manual adjustment of the brightness of the display.
    3)Top LED chip: Supplied by Silan of china & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display system.
    4)Clear vivid image quality: Throughout the show, the picture clear, bright color.
    5)Installation is simple,easy to use: Easy and simple installation interface and user friendly software to ensure that customers use easily.

    Outdoor RGB LED Full Color custom Display Flexible Module P4 High Resolution For Advertising 0


    __________________________________FAQ_________________________________________

    1. How long could i receive the inquiry reply ?
    A: You will get a reply within 24 hours.

    2.How long is the warranty?
    A: Different product offer different time frame warranty, but all product here we offer 1 year at least warranty.

    3.How is the after sales service ?
    A: We have a professional team which is in all around the world , also a service hot-line dealing with your complains and feedback.We also offer 24-hour online service to help you solving problems

    4.How long will it take to deliver goods ?
    A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment.
