Multiple Screen Statium LED Display Full Color Nova System Wifi 4G Outdoor P6.67

Multiple Screen Statium LED Display Full Color Nova System Wifi 4G Outdoor P6.67

    • Multiple Screen Statium LED Display Full Color Nova System Wifi 4G Outdoor P6.67
    • Multiple Screen Statium LED Display Full Color Nova System Wifi 4G Outdoor P6.67
  • Multiple Screen Statium LED Display Full Color Nova System Wifi 4G Outdoor P6.67

    Product Details:

    Place of Origin: China(Mainland)
    Brand Name: SCXK
    Certification: ISO,CE,FCC,UL
    Model Number: SCXK-P6.67

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 sqms
    Price: 700-800USD/sqm
    Packaging Details: Wooden and flight cases,it's up to you.
    Delivery Time: 12-15 working days after receiving your down payment.
    Payment Terms: T/T, Western Union
    Supply Ability: 5000 sqms/month
    Contact Now
    Detailed Product Description
    Pixel Pitch: 6.67mm Module Size: 320*160mm
    Cabinet Size: 640*640mm Control System: Nova
    Type Of Cabinet: Die-cast Aluminum/Iron Working Voltage: DC5V
    Outdoor Options: P3.91,P4,P4.81,P5,P5.95,P6,P6.67,P8,P10 Payment: T/T,Western Union
    High Light:

    perimeter led display

    ,

    perimeter led screen

    Multiple Screen Full Color Statium LED Display Nova System Wifi 4G Outdoor P6.67



    Our advantages



    1. Diversified products :

    Varieties of models for outdoor/indoor LED display screens,and customized cabinets available,meet all requirements and win more profits for customers.



    2. Experienced&Professional:

    10 years manufacturing experience on LED displays, professional workmanship & design.



    3. Best raw materials:

    Taiwan Epistar LED chip,high quality,high brightness and long life span.





    4. Competitive price:

    100% factory price,competitive and reasonable price.



    5. Strict quality control:

    100% testing before packing , make sure our quality before delivery.



    6. Quality gurantee:

    All our LED display screens is more than 100,000 hours life span.



    7. Long warranty:

    One year warranty, any quality problem during warranty time will be handled .



    8. Prompt &Professional service :

    Any inquires will be replied within 24 hours in working days and you’ll get helpful suggestions from us.



    Specifications of products:



    Statium LED Display P6.67
    Resolution/mm 6.67
    Pixel configuration 1R1G1B
    Pixel density/pixels/m² 22478/square meter
    Module resolution 48*24mm
    Module size/mm 320*160mm
    View distance 6-300m
    Single point brightness adjust Can be added
    Single point color adjust Can be added
    White balance brightness >8000cd/square meter
    Color temperature 6500K-9500K
    Horizontal view angle 120(degrees)
    Vertical view angle 60(degrees)
    Signal Process bit 10 or 16bit
    Grey process 1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distances Internet cable:100m, multimembrane:500m, monofilm:2km
    Driving mode

    alternating driving current

    Scanning mode 1/8 scanning mode
    Fresh rate 60Hz
    Refresh frequency >3000Hz
    Control mode

    Asynchronous,3G,4G,Wifi

    Brightness adjusted range Manual, automatic operation, stepless continuous adjusted
    255 steps. No grey loss
    Out of control point <1/10000
    Aging hours ≥72hours
    Mean Time Between Failure >5000hours
    Life time 100000hours
    Life-all-white(brightness halving) 50000hours
    Environment temperature range Operating temperature range: -20-45℃
    Self-check technology LED spot self-check, communications check, power check,
    temperature monitor(need customization)
    Remote monitoring Remote supervision and control, record potential fault,
    send out warning signs to the operators.(need customization)
    Software environment WindowsNT,Windows1999,WindowsXP
    Luminous point width between centres Deviation<3%
    Brightness uniformity <10%
    Waterproof Ip65
    Color uniformity(chromaticity coordinate) ±0.003
    Power supply request AC85-264V(50Hz-60Hz)
    Contrast (1000:1)
    System protection Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working) working:10-95%
    Humidity(storing) storing:10-95%



    Multiple Screen Statium LED Display Full Color Nova System Wifi 4G Outdoor P6.67 0

    ___________________________________About FAQ_______________________________________



    Q1:How to arrange payment?

    A:Our payment terms in usually is T/T payment,for sample and small order,Western union,Paypal or Moneygram also be acceptable



    Q2,What is our warranty?

    A:Our warranty from 5year to 1year basis on different type led screen,In usually every screen we will ready more extra led screen moduless as spare modules,if some modules happen fails,you can replace the fail modules by our spare modules,When all the spare modules use out,You can send back these modules to us for repair,and we will send to you after repair and testing&aging well



    Q3,How to be our distributor?

    A:To be our distributor,We can share our profit together with you in every year,Also we can send our engieer or sales to your compay to support your business,also for led screen after-service,We will together with you to the after-service in the whole led screen life time



    Q4, How to maintence led screen?

    A:In usually every year to maintence led screen one time,clear the led mask,checking the cables connection,if any led screen modules fail,you can replace it with our spare modules
