Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD

Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD

  • Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD
  • Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD
  • Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD
  • Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD
Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD
Product Details:
Place of Origin: China(Mainland)
Brand Name: SCXK
Certification: CE,ISO,FCC,UL
Model Number: SCXK-P5
Payment & Shipping Terms:
Minimum Order Quantity: 3 sqms
Price: 500-600USD/sqm
Packaging Details: Wooden and flight cases,it's up to you.
Delivery Time: 12-15 working days after receiving your down payment.
Payment Terms: T/T, Western Union
Supply Ability: 5000sqms/month
Contact Now
Detailed Product Description
Type: Full Color Led Display Kind Of Cabinets: Iron/Die Casting Cabinet
Module Size: 320*160MM Cabinet Size: 640*640MM
Waterproof: IP34 Application Place: Indoor
Resolution: 64*32 Brightness: 1200cd/sqm
Pixel Pitch: 5MM Pixel Density: 40000dots/sqm
Highlight:

rgb led curtain

,

led curtain screen

Hot Sale in China P5 Curtain LED Display Full Color Energy Conservation

Introduction of the cabinets:

We have two kinds of cabinets, one is iron cabinet and the other is die-cast cabinet.
Maybe you will be confused about this, then let me tell you.
Iron cabinet is used for fixed installation and is heavier. You can use it indoors and outdoors; die-cast cabinet is used for rental installation and is relatively light,
You can also use it indoors and outdoors, such as wedding parties, concerts, etc.
Therefore, for indoor use, you should pay attention to brightness, resolution, and especially
scan mode, because the viewing distance is close and the video needs to be vivid; for outdoor use,
waterproof is obviously important because of weather and some other uncertain situations.
Then the application place is also important, for your reference, if you use it on the road, then
the spacing can be large, which is enough. If you use it for concerts, then the spacing needs to be relatively small, but not too small, about 5 mm is fine.
First of all, you should understand 3 points before buying: indoor or outdoor, fixed or rental, and the picture effect you want. Then you can tell us these, and we will recommend the most suitable product for you.
Thank you for your time, waiting for your inquiry online!

Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD 0
Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD 1
Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD 2Outdoor High Brightness Display Waterproof Curtain LED Display 5MM Pixel Pitch Full Color Energy Saving HD 3
Specifications of product:

Indoor P5 LED screen Display
Resolution/mm5
Pixel configuration1R1G1B
Pixel density/pixels/m²40000/square meter
Module resolution64*32mm
Module size/mm320*160mm
View distance5-100m
Single point brightness adjustCan be added
Single point color adjustCan be added
White balance brightness>1200cd/square meter
Color temperature6500K-9500K
Horizontal view angle120(degrees)
Vertical view angle60(degrees)
Signal Process bit10 or 16bit
Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
Control distancesInternet cable:100m, multimembrane:500m, monofilm:2km
Driving modeConstant driving current
Scanning mode1/16
Fresh rate60Hz
Refresh frequency>3000Hz
Control modeComputer synchronous
Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
255 steps. No grey loss
Out of control point<1/10000
Working hours≥72hours
Mean Time Between Failure>5000hours
Life time100000hours
Life-all-white(brightness halving)50000hours
Environment temperature rangeOperating temperature range: -20-45℃
Self-check technologyLED spot self-check, communications check, power check,
temperature monitor(need customization)
Remote monitoringRemote supervision and control, record potential fault,
send out warning signs to the operators.(need customization)
Software environmentWindowsNT,Windows1999,WindowsXP
Luminous point width between centresDeviation<3%
Brightness uniformity<10%
WaterproofIP34
Color uniformity(chromaticity coordinate)±0.003
Power supply requestAC85-264V(50Hz-60Hz)
Contrast(1000:1)
System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
Humidity(working)working:10-95%
Humidity(storing)

storing:10-95%


The payment details:
1. We accept T/T, Western Union, 30% in advance, the balance 70% before delivery.
2. Delivery time (lead time): 12-15 working days after receiving the deposit.
3. Warranty: The warranty period is 2 years after delivery and free maintenance.
4. Free Training: You can send engineers with electronic knowledge to our factory for training. We will provide free training on how to operate, maintain and repair the LED display.
5. Technical support: We can send engineers to your country for guidance, but you must help us to apply for visas and pay the related costs, such as round-trip air tickets, hotels, meals and other costs after the engineers arrive in your country.

FAQ
Q1: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support cluster play and management. Support APP/Phone/ WIFI/ Ipad/ Laptop/ PC/ Cloud control. It’s very easy and convenient to control.
Q2: Can I have a sample order for led screen?
A: Yes, we welcome sample order to test and check quality. Mixed samples areacceptable.
Q3:Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q4: What is your best service?
1: One to one sales engineer to customer responsibility system;
2. Know your project and provide the best solution for it;
3. Track your order and let you know each step and detail of it;
4. Teach you how to install and use the screen;
5. Care the subsequent use of your screen and ensure your after - sales service be well.
Q5. How about your delivery time?
A: Generally, it will take 7-15 days after receiving your deposit. The specific delivery time depends on the items and the quantity of your order.
Q6:How about your Warranty Term?
A: 2-year warranty. Structure design, installation problem, system problem, how to use the screen…don’t worry, we have professional after-sale team to solve your any questions after you placed an order. And your exclusive sales engineer will also help you get over any problems.
